Cabletron Systems Fast Network 10 User Manual page 88

Chapter 5: FN10 Filters
Table 5-2 Port Filter Configuration Fields (Continued)
Field Description
Source The starting MAC address for the source range of
Range MAC addresses. If you are filtering on a single source
Start address, enter that address here.
Source Ending MAC address for the source range of MAC
Range addresses. If you are filtering on a single address,
End enter that address here.
Source
MAC address mask to apply to the range of source
Range
MAC addresses.
Mask
Either NA (not applicable), True
Destinati
the destination MAC address is within the range, or
on
False
Range
address is outside of the range.
Destinati
Starting MAC address for the destination range of
on
MAC addresses. If you are filtering on a single source
Range
address, enter that address here.
Start
Destinati
on Ending MAC address, for the destination range of
Range MAC addresses.
End
Destinati
on MAC address mask to apply to the range of
Range destination MAC addresses.
Mask
Either NA (not applicable), True
Protocol
the protocol type matches, or False
Match
if the protocol type does not match.
For all Ethernet-2, 802.3, or specific Ethernet frames.
All of the Ethernet hex values are listed in RFC 1060.
Protocol
Some common Ethernet protocol hex values include:
Type
0800 – IP, 0806 – ARP, 6003 – DECnet Phase IV, and
809B – AppleTalk
Either NA (not applicable), True
the masked value matches, or False
Field
if the masked value does not match. This option allows
Match
you to examine a portion of a packet to set up
customized filters to match conditions you specify.
Page 5-8
–
filter the packet if the destination MAC
–
filter the packet if
–
filter the packet if
–
filter the packet
–
filter the packet if
–
filter the packet
Fast Network 10 User Guide
Default
ff:ff:ff: ff:
ff:ff
NA
ff:ff:ff: ff:
ff:ff
NA
NA
