Chapter 1: Introduction

1.5.4.2 FN10's Fast Ethernet Option

The FN10, configured with the Fast Ethernet option, has two additional
ports that provide a fast Ethernet connection of 100 Mbps. Applying this
increased bandwidth to the previous example, the Manufacturing
Department's traffic to the corporate database could be transmitted to the
corporate database at the 100 Mbps rate.
Figure 1-7 illustrates connecting two FN10 Fast Ethernet ports to increase
the bandwidth to 100 Mbps.
Page 1-12
10BASE-T Cables
Network Switch
10BASE-T Cables
WAN Router
Figure 1-6 FN10 Application #2
Servers
FN10
Trunk Lines
FN10
Fast Network 10 User Guide
Network
Management
Station
Workgroup
Hub
