TECHNICAL SPECIFICATIONS

A.1 FN10 SPECIFICATIONS

Physical
Height
Width
Depth
Weight
Installation options
Electrical
Input voltage
Frequency
AC power consumption
Connector Ports
12 or 24 RJ45 Ethernet ports (MDI-X)
2 RJ45 Fast Ethernet ports (FE option)
1 AUI D-type, 15-pin female port
1 RS232C D-type, 9-pin female port using Point-to-Point (PPP)
or Local Console Manager (LCM)
2 optional Fast Ethernet Fiber Optic ST ports
Environmental
Operating temperature
Relative humidity
Diagnostic LEDs
Individual port link status (12, 24, or 26 with FE option)
Individual port segment status (12, 24, or 26 with FE option)
Segment status (5), specifying:
Transmit activity
Receive activity
Both Transmit and Receive activity
Collision
User-defined
Ready (1)
Power (Pwr) (1)
Fast Network 10 User Guide
APPENDIX A
1.75 in (4.45 cm) (1 u)
17 in (43.18 cm)
15.75 in (40 cm)
9 lb (4.1 kg)
Tabletop or rack-mount
Auto-ranging from 100-120, 200-240 Vac
50/60 Hz
80 watts
5 to 40 C (41 to 104 F)
0% to 95%, non-condensing
Page A-1
