Front Panel
Front Panel
Figure 1-8 illustrates how the FN10 can be used in a backbone network
configuration using increased bandwidth of the optional Fast Ethernet
configuration.
Fast Ethernet Switching
Fast Network 10 User Guide
LAN segment
FN10 / FE
FN10 / FE
LAN segment
Figure 1-7 FN10 Application #3
10BASE-T Cables
100 Mbps (Fast Ethernet)
10BASE-T Cables
WAN Router
Figure 1-8 FN10 Application #4
100 Mbps bandwidth
(Fast Ethernet)
Servers
Overview
Rear Panel
Rear Panel
Network
Management
Station
FN10
FN10
Workgroup
Hub
Page 1-13
