LED
Link (upper level of
port LEDs)
Status (lower level
of port LEDs)
Segment Status
TX
RX
Act
Col
Usr
Ready
Pwr
If the Ready LED continues to blink after power-up diagnostics
!
are complete, it could mean the FN10 is overheating.
CAUT ION
Fast Network 10 User Guide
Table 2-1 Meaning of FN10 LEDs
Meaning
On – Indicates the link is good.
Off – Indicates there is no link.
On/Blinking – Indicates you are monitoring the port for
a selected segment status condition.
Off – Indicates you are not monitoring the port.
On – Indicates you are monitoring Transmit (TX)
activity on all ports.
On – Indicates you are monitoring Receive (RX)
activity on all ports.
On – Indicates you are monitoring Transmit (TX) and
Receive (RX) activity on all ports.
On – Indicates you are monitoring packet collision on
all ports.
On – Indicates you are monitoring transmission and
receive errors on all ports.
On – Indicates the FN10 is operational.
Blinking – Indicates the FN10 is running power-up
diagnostics.
Off – Indicates the FN10 is non-operational.
On – Indicates the FN10 is receiving power and the
voltage is within the acceptable range.
Off – Indicates the FN10 is not receiving power.
FN10 Panels
Page 2-3
