Settings tab. This gives both the Friendly Name and the port name (
identifies the physical port that will be used to communicate with the device.
Open the device using either of the previous names. Use whatever facility is provided by your
development environment for opening files. For Visual Basic, do the following:
'set error handling
On Error Resume Next
'open the port for binary access
Open "\\.\micr+" For Binary Access Read Write As #1
If Err.Number <> 0 Then
<<process error>>
End If
on error goto 0
The friendly name of the device, as found in the operating system's
device UI (Device Manager in Windows 95, for example), must be
prefixed with "
example did not have the prefix, it would create a file named
micr+
Interacting with the device
An application interacts with the device by sending commands to the device and reading its
responses. Commands are sent by writing to the opened port and responses from the device or
property requests are retrieved by reading from the port.
To interact with the device using the MSComm component, invoke a command by assigning it to
MSComm's
Output
as a event or by directly polling the port. The entire response to a command or
comEvReceive
property request is received as a single event.
'submit echo command
Comm.Output = "/echo Hello" + Chr$(10)
Private Sub Comm_OnComm()
'return if not a receive event
If Comm.CommEvent = comEvReceive Then
'process received data
a$ = Comm.Input
Else
<<process non-read event>>
End If
End Sub
If using file I/O access, interaction with the device is indistinguishable from writing to or reading
from a file.
" in order to open the device. If the previous
\\.\
in the current directory–clearly not the desired result.
property. The response is received by MSComm's
'get echo data
Note
Section 1. Overview
). It also
COM<5-15>
event handler
OnComm
