Brother CB200 Service Manual page 84

Trouble
(6) Black vertical streaks
(7) Light or dark
(8) Image distortion
(9) Blurred image
(10) Not aligned horizontally
At the scanner
Set the scanning compensation parameters in the EEPROM
l
(Function code 55 in Subsection 4.3.1).
Clean the copyboard screen around the two black HP marks.
l
Clean the CIS units.
l
Check the CIS unit(s).
l
At the printer
Check the following components:
l
- Thermal recording head
- Main PCB
At the scanner
Check the scanning contrast setting (Function code 07 in
l
Subsection 4.3.2).
Set the scanning compensation parameters in the EEPROM
l
(Function code 55 in Subsection 4.3.1).
Clean the copyboard screen around the two black HP marks.
l
At the printer
Check the following components:
l
- Compression springs under the thermal recording head
At the scanner
Check the following components:
l
- WB motor
- Pipe holders and their gears and springs
At the printer
Check that recording paper is loaded correctly.
l
Check the printer motor.
l
Clean the platen with alcohol.
l
At the scanner
Adjust the gap between the CIS frame and the copyboard
l
screen using positioning jigs. (Refer to Subsection 3.1.2, [ 1
], Reassembly notes.)
At the scanner
Remove the three CIS units from the CIS frame, then
l
reinstall them while pressing each of those units and CIS
frame to each other in order to align those units with each
other. (Refer to Subsection 3.1.2, [ 1 ], Reassembly notes.)
V - 10
Action to be taken
