N Tightening Torque List - Brother CB200 Service Manual

n n Tightening Torque List
Location
PRINTER
Platen stopper
Platen frames R and L
Printer support
Sub cover
Panel cover
Control panel PCB
Main PCB
Drive unit
Printer motor cover
Printer motor
Hinge plate L
Recorder frame
PE/cover sensor PCB
COPYBOARD
Upper cover
Corner covers (upper)
CIS protector (upper)
Upper support frame
CIS frame
CIS units
Lower cover
Corner covers (lower)
CIS protector (lower)
Lower support frame
PCB support
Relay PCB
Printer-copyboard interface cable
Lower corner plates R and L
Lower frame
Pipe holder stoppers
WB motor
Side covers R and L
Screw type
Taptite, pan B M4x20
Taptite, bind B M4x12
Taptite, cup S M3x6
Taptite, bind B M4x12
Taptite, bind B M4x12
Taptite, bind B M4x12
Taptite, cup B M3x8
Taptite, cup S M3x6
Taptite, bind B M4x12
Taptite, cup S M3x6
Screw, pan (s/p washer) M3x6DB
Taptite, bind B M4x12
Taptite, bind B M4x12
Taptite, cup S M3x6
Shoulder screw
Screw, flat S M3x10
Taptite, cup S M3x10
Taptite, cup S M3x10
Taptite, cup S M3x10
Taptite, bind B M3x8
Shoulder screw
Screw, flat S M3x10
Taptite, cup S M3x10
Taptite, cup S M3x10
Taptite, cup S M3x10
Taptite, cup S M3x6
Taptite, cup S M3x10
Taptite, cup S M3x10
Taptite, washer S M3x10
Taptite, bind B 3x8
Taptite, cup S M3x8
Screw, pan (s/p washer) M3x6DB
Taptite, cup S M3x10
III - 2
Q'ty Tightening torque (N m)
1 0.69 0.1
4 0.98 0.2
2 0.69 0.1
2 0.98 0.2
1 0.98 0.2
2 0.98 0.2
2 0.69 0.1
2 0.69 0.1
2 0.98 0.2
1 0.69 0.1
1 0.69 0.1
2 0.98 0.2
2 0.98 0.2
1 0.69 0.1
3 0.78 0.1
4 0.78 0.1
2 0.78 0.1
2 0.78 0.1
4 0.78 0.1
6 0.39 0.1
3 0.78 0.1
4 0.78 0.1
2 0.78 0.1
2 0.78 0.1
2 0.78 0.1
2 0.78 0.1
2 0.78 0.1
4 0.78 0.1
1 0.78 0.1
2 0.69 0.1
2 0.78 0.1
2 0.78 0.1
6 0.78 0.1
