GETTING STARTED

This section helps you get ready to install your MERLIN communications system. Begin by
checking the floor plan that you prepared with your order, verifying the equipment received,
and getting the tools you need. After you complete each step, check it off in the box on the
left.
A.

Checking the Floor Plan

Check the floor plan that you prepared when you ordered your system, to make sure
that it agrees with the layout of the installation location. Figure 1 show a typical sys-
tem.
10–BUTTON
VOICE TERMINAL
D8AF TERMINAL
EXTENSION
CORD
D8W MODULAR
TERMINAL CORD
Figure 1
MODEL 206 CONTROL UNIT
NETWORK
INTERFACE
MODULAR
LINE
CORDS
4
