INSTALLING THE CONTROL UNIT
This section explains how to position the control unit, install the cartridges, supply power to
the control unit, connect the control unit to the network interface, and set the control unit
switches (Figure 3).
AC
AC
OUTLET
POWER
CORD
INSTALLATION
D4CH MODULAR
LINE CORDS
TWO–
LINE
ADAPTER
Figure 3
LOCAL TELEPHONE
EXCHANGE SERVICE
COMPANY
NETWORK
INTERFACE
LOCAL
TELEPHONE
EXCHANGE
SERVICE
COMPANY
LINES
13
