DGS-3100 Series Gigabit Stackable Managed Switch User Manual
The MLD Snooping & Static Router Ports Settings Page contains the following fields:
Field
VLAN ID
VLAN Name
Done Timer (0-16711450 sec)
Host Timeout (60-16711450 sec)
Router Timeout (1-16711450 sec)
State
81
Figure 3–14. MLD Snooping & Static Router Ports Settings Page
Description
Specifies the VLAN ID
Displays the user-defined VLAN name.
Defines the time interval in seconds after which a port is removed from the
Multicast membership group. Ports are removed from the Multicast
membership when the port sends a Done Message, indicating the port requests
to leave the Multicast group. The field range is 0 - 16711450 seconds. The
default timeout is 10 seconds.
Defines the time interval in seconds after which a port is removed from a
Multicast Group. Ports are removed if a Multicast group MLD report was not
received from a Multicast port within the defined Host Timeout period. The
possible field range is 60 - 16711450 seconds. The default timeout is 260
seconds.
Defines the time interval in seconds the Multicast router waits to receive a
message before it times out. The possible field range is 1 - 16711450 seconds.
The default timeout is 300 seconds.
Indicates if MLD snooping is enabled on the VLAN. The possible field values
are:
Enable — Enables MLD Snooping on the VLAN.
Disable — Disables MLD Snooping on the VLAN
