View
5 Device
Application Buttons
6 Stacking Status
View
Description
the Switch's ports and expansion modules, showing port activity, duplex mode, or flow
control, depending on the specified mode.
Various areas of the graphic can be selected for performing management functions, including
port configuration
Provides access to the device logout, and provides information about the Safe Guard mode
currently enabled on the device.
Provides a graphic representation of the stacking links and ports status.
Table 1-2. Main Areas
DGS-3100 Series Gigabit Stackable Managed Switch User Manual
