NETGEAR FS728TPv2 Software Administration Manual page 198

Field
Broadcast Storm Recovery
CFI Discards
Upstream Threshold
Total Packets Transmitted
(Octets)
Packets Transmitted 64
Octets
Packets Transmitted
65-127 Octets
Packets Transmitted
128-255 Octets
Packets Transmitted
256-511 Octets
Packets Transmitted
512-1023 Octets
Packets Transmitted
1024-1518 Octets
Packets Transmitted
1519-1522 Octets
Total Packets Transmitted
Successfully
Unicast Packets
Transmitted
Multicast Packets
Transmitted
198 | Chapter 6: Monitoring the System
FS728TP Smart Switch Software Administration Manual
Description
The number of frames discarded that are destined for FF:FF:FF:FF:FF:FF
when Broadcast Storm Recovery is enabled.
The number of frames discarded that have CFI bit set and the addresses in
RIF are in non-canonical format.
The number of frames discarded due to lack of cell descriptors available for
that packet's priority level.
The total number of octets of data (including those in bad packets) transmitted
on the network (excluding framing bits but including FCS octets). This object
can be used as a reasonable estimate of ethernet utilization. If greater
precision is desired, the etherStatsPkts and etherStatsOctets objects should
be sampled before and after a common interval.
The total number of packets (including bad packets) transmitted that were 64
octets in length (excluding framing bits but including FCS octets).
The total number of packets (including bad packets) transmitted that were
between 65 and 127 octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets) transmitted that were
between 128 and 255 octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets) transmitted that were
between 256 and 511 octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets) transmitted that were
between 512 and 1023 octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets) transmitted that were
between 1024 and 1518 octets in length inclusive (excluding framing bits but
including FCS octets).
The total number of packets (including bad packets) transmitted that were
between 1519 and 1522 octets in length inclusive (excluding framing bits but
including FCS octets).
The number of frames that have been transmitted by this port to its segment.
The total number of packets that higher-level protocols requested be
transmitted to a subnetwork-unicast address, including those that were
discarded or not sent.
The total number of packets that higher-level protocols requested be
transmitted to a Multicast address, including those that were discarded or not
sent.
