Smart Bandwidth Limit
User-defined Bandwidth
Limit
When you finish adding a new bandwidth limit, simply click OK.
Vigor2750 Series User's Guide
Click this radio button to configure the default limitation for
bandwidth.
When session number exceeds – type the value here as a
threshold to apply the smart bandwidth limit.
TX limit - Define the default speed of the upstream for
each computer in LAN.
RX limit - Define the default speed of the downstream for
each computer in LAN.
Click this radio button to configure the user-defined
limitation for bandwidth.
Limitation List - Display a list of specific limitations that
you set on this web page.
Start IP - Bandwidth limit can be applied on certain IP
range. That's, only the PCs within the range will be
influenced by the bandwidth limitation set here. Please
define the start IP address for the specific limitation.
End IP - Define the end IP address for the specific
limitation.
TX Limit - Define the limitation for the speed of the
upstream to be applied as specific limitation. If you do not
set the limit in this field, the system will use the default
speed for the specific limitation you set for each index.
RX Limit - Define the limitation for the speed of the
downstream to be applied as specific limitation. If you do
not set the limit in this field, the system will use the default
speed for the specific limitation you set for each index.
Add - Add the specific speed limitation onto the list above.
Edit - Allows you to edit the settings for the selected
limitation.
Delete - Remove the selected settings existing on the
limitation list.
61
