Page 1 ProLiant 8500 Servers Setup and Installation Guide First Edition (May 1999) Part Number 323333-001 Compaq Computer Corporation...
Page 2 MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, GOOD TITLE AND AGAINST INFRINGEMENT. This publication contains information protected by copyright. No part of this publication may be photocopied or reproduced in any form without prior written consent from Compaq Computer Corporation. © 1999 Compaq Computer Corporation.
Page 3: Table Of Contents
Where to Go for Additional Help ................xii Integrated Management Display................xii Telephone Numbers................... xiii Chapter 1 Introduction Compaq ProLiant 8500 Servers................1-1 Features ........................1-3 Processor and Redundant Processor Power Modules........1-3 System Memory....................1-4 Cache Accelerator....................1-4 Expansion Slots ....................1-4 PCI Hot Plug......................
Page 4 Compaq ProLiant 8500 Servers Setup and Installation Guide Introduction continued Major Hardware Options ..................1-9 Server Configuration and Management .............. 1-10 Compaq SmartStart ..................1-10 Compaq System Configuration Utility ............1-10 Windows NT Utilities................. 1-11 NetWare Utilities..................1-11 Compaq Insight Manager................1-11 Compaq Integrated Management Log............
Page 5 About This Guide v Server Installation continued Cabling the Server ..................... 2-26 Powering Up the Server..................2-28 Powering Down the Server ................2-29 Chapter 3 Server Operation System Power...................... 3-2 Power Supply Indicators ................3-3 Numbering of Power Supplies............... 3-4 System Interconnect Status Indicators ..............
Page 6 Compaq ProLiant 8500 Servers Setup and Installation Guide Chapter 5 SCSI Setup Features........................5-1 Installing the Integrated Array Bypass ..............5-3 Procedure......................5-3 Option ROM-Based Array Configuration Utility............5-6 Array Configuration Utility ..................5-7 Starting the Compaq Array Configuration Utility.............5-8 On-line Help .......................5-8 Capacity Expansion....................5-8 Capacity Extension.....................5-9...
Page 7: Index
About This Guide vii Chapter 8 Initial Startup and Troubleshooting Powering on the Server..................... 8-1 System Interconnect Status Indicators..............8-3 Running System Diagnostics..................8-5 Appendix A Regulatory Compliance Notices Regulatory Compliance Identification Numbers............A-1 Federal Communications Commission Notice ............A-1 Class A Equipment ....................A-2 Modifications.....................A-3 Cables ........................A-3 Canadian Notice (Avis Canadien) ................A-3...
Page 8: About This Guide
This Setup and Installation Guide can be used for step-by-step instructions for installation, and as a reference for operation, troubleshooting, and future upgrades for Compaq ProLiant 8500 Servers. WARNING: To reduce the risk of personal injury from electrical shock and hazardous energy levels, only authorized service technicians should attempt to repair this equipment.
Page 9: Symbols In Text
Compaq ProLiant 8500 Servers Setup and Installation Guide Symbols in Text These symbols may be found in the text of this guide. They have the following meanings. WARNING: Text set off in this manner indicates that failure to follow directions in the warning could result in bodily harm or loss of life.
Page 10: Compaq Technician Notes
Compaq Technician Notes WARNING: Only authorized technicians trained by Compaq should attempt to repair this equipment. All troubleshooting and repair procedures are detailed to allow only subassembly/module level repair. Because of the complexity of the individual boards and subassemblies, no one should attempt to make repairs at the component level or to make modifications to any printed wiring board.
Page 11: Where To Go For Additional Help
Compaq ProLiant 8500 Servers Setup and Installation Guide WARNING: To reduce the risk of electric shock or damage to the equipment: If the system has multiple power supplies, disconnect power from the system by unplugging all power cords from the power supplies.
Page 12: Telephone Numbers
In the United States, call 1-800-345-1518 In Canada, call 1-800-263-5868 For Compaq technical support: In the United States and Canada, call 1-800-386-2172 For Compaq technical support phone numbers outside the United States and Canada, visit the Compaq website at: http://www.compaq.com...
Page 13: Introduction
The Compaq ProLiant 8500, the ultimate high-density data center server, delivers breakthrough 8-way scalable performance for 24x7 multi-server rack environments. The ProLiant 8500, which is based on the ProFusion 8-way architecture, delivers this performance through state-of-the-art Intel Pentium III Xeon processor technology, breakthrough scalable performance of I/O and memory, and the highest levels of fault tolerance and manageability for the data center.
Page 14 1-2 Compaq ProLiant 8500 Servers Setup and Installation Guide In Compaq ProLiant 8500 servers, you can access options and accessories easily through a sliding top access panel and three removable modules: the Processor and Memory module, the Media module, and the I/O Module. See Figures 2-1 and 2-2 for identification of these modules and other components.
Page 15: Features
1 I/O module with system fans 2 Integrated Server Lift Handles 3 Hot Plug Power Supplies Features The following features are available on Compaq ProLiant 8500 models: Processor and Redundant Processor Power Modules Supports up to eight Pentium III Xeon processors...
Page 16: System Memory
1-4 Compaq ProLiant 8500 Servers Setup and Installation Guide System Memory ECC (Error Checking and Correcting Memory) with single-bit error correction and detection to a single DIMM, and multi-bit error detection to the memory bank Supports 100 MHz Registered SDRAM...
Page 17: Redundant Hot Plug Fan
Introduction 1-5 Redundant Hot Plug Fan ProLiant 8500 servers include a redundant hot-plug system fan. If the primary fan fails, it generates a system alert and triggers the secondary (or redundant) fan to take over automatically. The redundant hot-plug system fan protects the various server components from overheating and possible system interruption.
Page 18: Network Controller
1-6 Compaq ProLiant 8500 Servers Setup and Installation Guide Network Controller Supports a dual-port 10/100 TX UTP controller on the PCI local bus (on some models). Features of the controller include two RJ-45 connectors for 10BaseT or 100TX Ethernet. For information about the network controller, refer to the Compaq Web Site at www.compaq.com.
Page 19: Power Supplies
Power Down Manager Utility under Microsoft Windows NT Power Supply Utility under NetWare The utilities are provided on the Compaq Support Software for Microsoft Windows NT 4.0 diskettes (NTSSD). For more detailed information, refer to the NTREADME.HLP file on Diskette 1.
Page 20: Remote-Flash Redundant Rom
1-8 Compaq ProLiant 8500 Servers Setup and Installation Guide System Power Management Guidelines Unless operating with two 1150W power supplies at 220V, it may be necessary to make tradeoffs with respect to which options can be added and powered with the installed power supplies. Use the following guidelines when evaluating these tradeoffs.
Page 21: Introduction
ROMPaq diskette. Once the flash process is completed the server now contains a fully redundant system ROM. NOTE: If you are familiar with the process of flashing a Compaq server via the ROMPaq utility there are no noticeable changes to the ROMPaq user interface. This feature is implemented in the ROMPaq driver and the system boot block only.
Page 22: Server Configuration And Management
1-10 Compaq ProLiant 8500 Servers Setup and Installation Guide Server Configuration and Management Compaq offers an extensive set of features and tools to support effective server configuration and management. Some are listed below: Compaq SmartStart Compaq System Configuration Utility Compaq Remote-Flash ROM...
Page 23: Windows Nt Utilities
Compaq Insight Manager is the Compaq application for easily managing network desktops and servers. Compaq Insight Manager delivers intelligent monitoring and alerting as well as visual control of your Compaq servers and desktops. In the unlikely event of hardware failures, Compaq Insight Manager...
Page 24: Compaq Integrated Management Log
Compaq Web-Based Management Compaq Web-Based Management allows you to access your managed Device List and the Compaq Insight Manager Alarm Log with a web browser, either locally at the management console or from another machine. If you have devices that are running Compaq Insight Management Agents v4.x, you can also view the device data using a browser.
Page 25: Compaq Integrated Management Display
For detailed information about security features, refer to the Systems Reference Library CD included in the Reference Information pack shipped with your server. Software Security Features These software security features are established through the Compaq System Configuration Utility. Administrator Password Diskette Drive Control...
Page 26: Hardware Security Features
These hardware security features are established by a switch on the I/O board. Configuration Lock Diskette Boot Control Service Features Some of the software, firmware, and hardware features of the Compaq ProLiant 8500 server that facilitate serviceability include: Modular design All diagnostic LEDs viewable from the exterior...
Page 27: Server Installation
Chapter Server Installation This chapter provides the procedures required to prepare a ProLiant 8500 server to be mounted in a Compaq or industry-standard 19-inch rack, and to complete installation. Preparing the Server Installing the server in the rack requires the following steps (detailed later in this chapter): 1.
Page 28: Optimum Environment
Setup and Management pack shipped with your server. 12. Register the server. For server registration information, refer to the Server Setup and Management pack shipped with your server. Optimum Environment When installing your ProLiant 8500 in a rack, the following standards must be met: Space Power...
Page 29: Space Requirements
Server Installation 2-3 Space Requirements Consider the following items when deciding where to install your Compaq rack: Clearance in the front of the rack should be a minimum of 25 inches for servicing. Clearance in the back of the rack should be a minimum of 30 inches to allow for servicing and for adequate airflow.
Page 30: Grounding
Due to the higher ground leakage currents associated with the equipment, Compaq recommends the use of a Power Distribution Unit (PDU) that provides a supplementary ground conductor. This supplementary ground conductor should be permanently connected to a suitable building ground terminal.
Page 31: Rack Internal Temperature
Make sure that the option equipment does not impede airflow to the Rack- Mountable ProLiant Servers or increase the internal rack temperature beyond the Compaq specified maximum rating. Make sure that the Manufacturer’s Maximum Recommended Ambient Operating Temperature of the option equipment is not exceeded when...
Page 32: Airflow Requirements
2-6 Compaq ProLiant 8500 Servers Setup and Installation Guide Airflow Requirements The Compaq ProLiant 8500 server draws cool air in through the front door and exhausts warm air out through the rear door. Therefore, the front door of the rack must be adequately ventilated to allow ambient room air to enter the cabinet, and the rear door must be ventilated adequately to allow the warm air to escape from the cabinet.
Page 33: Unpacking The Shipping Boxes
Unpack the shipping boxes by following the instructions and illustrations printed on the outside of the boxes. Locate the following materials: ProLiant 8500 Server - located inside shipping box Power cord(s) - located inside country kit box Documentation inside the server (Most of the option installation and setup instructions are located on hood labels on top of the unit and on the sides of the Processor and Memory module.)
Page 34: Removing The Shipping Brackets And Screws
2-8 Compaq ProLiant 8500 Servers Setup and Installation Guide Removing the Shipping Brackets and Screws To protect the power supply and I/O Module from any damage during shipment, each is installed with a protective covering bracket. Use the following illustration to loosen the screw and remove the bracket.
Page 35 Server Installation 2-9 Figure 2-2. Removing the I/O Shipping bracket The ProLiant 8500 server has a top latch security screw as shown in the following figure. The top latch security screw is provided to prevent access to the Processor and Memory module and the I/O module. If this screw is locked, loosen it as shown in the figure.
Page 36 2-10 Compaq ProLiant 8500 Servers Setup and Installation Guide Slide the top access panel open. Figure 2-4. Opening the top access panel Loosen the shipping screw between the Host Module and the I/O Module as shown in the following figure.
Page 37: Locating The Server Access Panel Labels And System Interlock Status Indicators
Server Installation 2-11 Locating the Server Access Panel Labels and System Interlock Status Indicators A significant amount of server configuration and options installation information is provided on the panel labels. As shown in the following figure, these labels are located on the top of the unit and on the sides of the Processor and Memory module.
Page 38: Rack Warnings And Precautions
IMPORTANT: The Compaq Installing Rack Products CD is included with the server. You may also want to refer to the following documentation: Rack Resource CD Kit (shipped with Compaq racks or available through a Compaq authorized reseller) Rack Builder Configuration Tool CD (available on the Compaq website or can be...
Page 39: Attaching The Slide Rails To The Server
Server Installation 2-13 CAUTION: Because the ProLiant 8500 server does not have safety interlocks, it is possible for a unit to be operated without the cover and air baffles properly installed. This could cause thermal damage in the system and may void your warranty.
Page 40: Attaching The Slide Rails To The Mounting Brackets
2-14 Compaq ProLiant 8500 Servers Setup and Installation Guide Attaching the Slide Rails to the Mounting Brackets The slide rails and mounting brackets form assemblies that attach to the rack. To attach the slide rails to the mounting bracket: 1. Locate the slide rails and the mounting brackets.
Page 41 Server Installation 2-15 3. Align the front screw holes in the slide rail and the mounting bracket. 4. Fasten the slide rail to the mounting bracket with three 8-32 x 1/4-inch slotted screws (supplied). Figure 2-9. Attaching the slide rail to the mounting bracket 5.
Page 42: Attaching The Slide Rail Assembly To The Rack
2-16 Compaq ProLiant 8500 Servers Setup and Installation Guide Attaching the Slide Rail Assembly to the Rack Attaching the slide rail assembly to the rack consists of the following: Marking the server’s rack position with the template Installing the slide rail assembly on the rack...
Page 43 Server Installation 2-17 3. Remove the template from the rack by grasping the middle of the top and bottom edges and gently pulling the template as shown in the following figure. This should allow the template to pull away from the plastic rail covers leaving the rail covers in place.
Page 44: Inserting Cage Nuts Into The Rack Frame
2-18 Compaq ProLiant 8500 Servers Setup and Installation Guide Inserting Cage Nuts into the Rack Frame The cage nuts fit inside the rails at the marked locations. 1. Use the cage nut fitting tool to insert a cage nut into the rails. Squeeze the prongs together 1 and insert the cage nut into the appropriate hole in the rack 2.
Page 45: Installing The Slide Rail Assembly To The Rack
Server Installation 2-19 Installing the Slide Rail Assembly to the Rack To install the slide rail assembly: 1. Place a mounting bracket in position according to the pencil marks made earlier. 2. Attach the front of the bracket on the inside of the front of the rack with one M6 x 1.0-12L Phillips screw in the bottom hole as shown in the following figure.
Page 46: Installing The Server Into The Rack
The unit will be unstable when not mated with the rails. IMPORTANT: To reduce the weight of the system, Compaq recommends that all power supplies, Processor and Memory Module, and Media Module should be removed from the system before loading in onto the rails...
Page 47 Server Installation 2-21 1. Extend the slides fully. Figure 2-15. Extending the slides 2. Remove the modules to lighten the chassis if desired (See Chapter 3, “Server Operation” for removal instructions.) 3. Lift the server with the recessed Integrated Server Lift Handles. 4.
Page 48 2-22 Compaq ProLiant 8500 Servers Setup and Installation Guide Figure 2-16. Setting the server on the slide rails 5. Slide the server between the extended slides as far as it will go. WARNING: To reduce the risk of personal injury, be careful when pressing the component rail release latches and sliding the component into the rack.
Page 49: Attaching The Cable Management Arm Bracket And Cable Management Arm
Server Installation 2-23 Attaching the Cable Management Arm Bracket and Cable Management Arm The cable management bracket and arm assembly lets you organize and secure the cables in the back of the server. The cable management arm attaches to the cable management arm bracket on the server and to the rack.
Page 50: Installing The Cable Management Arm
To attach the cable management arm: NOTE: The following procedure describes installing the Cable Management Arm supplied with the ProLiant 8500 server. For complex rack installations including a large number of cables, you can obtain an optional High Capacity Cable Management Arm available as an option kit, part number 124711-B21.
Page 51: Server Installation
Server Installation 2-25 3. Align the other end of the cable management arm on the outside of the rear rack frame. Attach the end with the M6 x 1.0-12L washer face Phillips-head screws. Figure 2-19. Attaching the cable management arm to the rack...
Page 52: Cabling The Server
2-26 Compaq ProLiant 8500 Servers Setup and Installation Guide Cabling the Server 1. Connect the power cord(s) and peripheral devices such as the keyboard, mouse, and monitor. The following figure and table identifies the peripheral connectors on the back of the server.
Page 53 Server Installation 2-27 2. Secure the AC cord with the retention clip provided on the power supply, as shown in the following figure, to prevent the cord from being accidentally disengaged. Figure 2-21. Securing the power cord with the loop provided WARNING: To reduce the risk of electric shock or damage to the equipment: Install the power supply before connecting the power cord to the power supply.
Page 54: Powering Up The Server
6. Extend the bundled cables down the rack’s cable channel. Powering Up the Server You can now bring your ProLiant 8500 server online in accordance with your network and operating system procedures. Press the momentary Power On/Standby switch to turn the system on. The power LED may blink for a few seconds until full power is on.
Page 55: Powering Down The Server
Powering Down the Server The system power in the ProLiant 8500 does not shut off completely with the front panel Power On/Standby switch. The two modes of the switch are ON and STANDBY, rather than ON and OFF. The STANDBY position removes...
Page 56: Server Operation
Chapter Server Operation The ProLiant 8500 Server provides easy access to all internal components for installation and maintenance. The information below provides details concerning system power and power supply indicators and removal of the server modules. WARNING: The power supplies in the ProLiant 8500 server produce hazardous energy levels.
Page 57: System Power
3-2 Compaq ProLiant 8500 Servers Setup and Installation Guide System Power The system power in the ProLiant 8500 Server does not shut off completely with the front panel Power On/Standby switch. The two modes of the power switch are ON and STANDBY, rather than ON and OFF. The STANDBY...
Page 58: Power Supply Indicators
Server Operation 3-3 Power Supply Indicators Each power supply has status and AC power indicators. See Figure 3-1 and Table 3-1 for a detailed description of both indicators. Figure 3-1. Power supply indicators Table 3-1 Power Supply Indicators Indicator Condition Meaning Green Normal operation...
Page 59: Numbering Of Power Supplies
3-4 Compaq ProLiant 8500 Servers Setup and Installation Guide Numbering of Power Supplies The ProLiant 8500 server is provided with the capability for two hot-plug, redundant power supplies. See Chapter 4, “Installing Hardware Options,” or the option documentation to replace a power supply.
Page 60: System Interconnect Status
Server Operation 3-5 Figure 3-3. Accessing system interconnect status LEDs Table 3-2 System Interconnect Status Indicators Indicator Component Indicator Component Emergency Shutdown Termination PPM Processor 8 Memory Board Processor 7 Processor/Memory Module Processor 6 I/O Module Processor 5 Media Module Processor 4 SCSI backplane 1 Processor 3...
Page 61: Server Access Panel And Modules
3-6 Compaq ProLiant 8500 Servers Setup and Installation Guide Server Access Panel and Modules The Compaq ProLiant 8500 server chassis facilitates the installation of hardware upgrades through the use of three removable modules and a sliding top access panel. The following table describes the contents of the modules and how to how to access the components.
Page 62: Accessing The I/O Module
Server Operation 3-7 Accessing the I/O Module To open the I/O Module to install or replace hot-plug fans or hot-plug PCI boards: 1. Slide the chassis out of the rack. 2. Lift the forward most edges of the top access panel, as indicated by the arrows in the following figure, and slide it toward the front of the server.
Page 63 3-8 Compaq ProLiant 8500 Servers Setup and Installation Guide 2. Push in on the sides of the cam levers 1 on the I/O Module and rotate the top of the levers downward 2 as shown in the following figure. Figure 3-5. Removing the I/O Module 3.
Page 64: Opening The Processor And Memory Module
Server Operation 3-9 5. Set the module aside for servicing non hot-plug components. WARNING: To reduce the risk of personal injury from hot surfaces, allow the internal system components to cool before touching them. CAUTION: Never operate the server for extended periods of time, with an access panel or module removed or partially installed.
Page 65: Removing The Processor And Memory Module
3-10 Compaq ProLiant 8500 Servers Setup and Installation Guide Figure 3-7. Opening the Processor and Memory Module Removing the Processor and Memory Module 1. Follow steps 1 through 3 of the preceding section, “Opening the Processor and Memory Module.” 2. Press the module stop latches 2 in and pull the module out of the chassis 1 as shown in the following figure.
Page 66: Processor Serial Number
The Processor Serial Number is a Pentium III Xeon processor manageability feature. It can be used for network inventory and tracking purposes. Compaq ProLiant 8500 servers are shipped with this feature disabled. You can enable the feature using the System Configuration utility.
Page 67 3-12 Compaq ProLiant 8500 Servers Setup and Installation Guide Figure 3-9. Opening the media module 4. Press the module stop latches in and pull the module out of the chassis. 5. Set the module aside for adding or replacing the diskette drive or CD-ROM drive as described in Chapter 4, “Installing Hardware...
Page 68: Imd
Server Operation 3-13 Refer to the following figure to identify components in the Media Module. Figure 3-10. Media Module components 1 CD-ROM drive signal/power 5 Power switch/LED and cable thermistor cable 2 Diskette drive signal cable 6 Media backplane assembly 3 Diskette drive power cable 7 SCSI backplane assembly 1 4 IMD signal/power cable...
Page 69: Installing Hardware Options
Compaq recommends that you use the documentation provided with the hardware option for complete installation instructions. You can also refer to the Compaq ProLiant 8500 Hardware Installation and Configuration poster included in the shipping box or the labels attached to the top panel of the server.
Page 70: Installing A Hot-Plug Power Supply
Installing a Hot-Plug Power Supply The ProLiant 8500 ships with either one or two hot-plug power supplies depending on the model. The system power in the ProLiant 8500 Server does not have to be shut off to replace one of the power supplies.
Page 71 Installing Hardware Options 4-3 3. Rotate the power supply handle down 2 and slide the supply out of the chassis 3 as shown in the following figure. NOTE: When you remove the power supply, a spring-loaded trap door will close to block the opening.
Page 72 4-4 Compaq ProLiant 8500 Servers Setup and Installation Guide Figure 4-3. Securing the hot-plug power supply 8. Plug in the power cord. If desired, use the plastic retainer to secure the AC cord to the plastic loop provided on the power supply. Leave an 8-inch service loop for the plug.
Page 73: Installing A Pentium Iii Xeon Processor And Processor Power Module
Installing a Pentium III Xeon Processor and Processor Power Module The ProLiant 8500 ships with one to eight Pentium III Xeon processors installed, and it is capable of supporting up to eight processors and eight processor power modules. Each processor requires an associated processor power module.
Page 74: Processor/Processor Power
4-6 Compaq ProLiant 8500 Servers Setup and Installation Guide Figure 4-6. Processor board layout Table 4-1 Processor/Processor Power Module Socket and Associated Bus/Core Ratio Switch Locations Item Component Item Component Processor Socket 1 and associated Processor Socket 8 and Power Module Socket...
Page 75 Installing Hardware Options 4-7 To install a processor power module and a Pentium III Xeon processor in the Processor and Memory Module, refer to one of the following installation sources: For a text and illustrated procedure, refer to the documentation provided with the option kit.
Page 76: Processor Bus/Core Ratio Switch
4-8 Compaq ProLiant 8500 Servers Setup and Installation Guide 4. Rotate the ejector levers 1 fully to unseat the processor terminator board from the socket. Remove the processor terminator board by pulling it out by the handle 2. Retain for future use.
Page 77 Installing Hardware Options 4-9 NOTE: The Pentium III Xeon processor and processor power modules are keyed to ensure correct alignment. Refer to the option documentation for the latest bus/core ratio switch settings. 8. Align the new processor power module with the processor power module socket.
Page 78 4-10 Compaq ProLiant 8500 Servers Setup and Installation Guide 9. Align the new Pentium III Xeon processor with the processor socket. Install the processor 1, and rotate the ejector levers inward 2 to fully seat and lock the processor. Figure 4-10. Installing the Pentium III Xeon processor NOTE: If you have installed processors to a total of five or more, you must install Cache Accelerator modules.
Page 79: Installing The Cache Accelerator
ProLiant 8500 servers have two processor buses. In the following figure, processor sockets 1 through 4 are on processor bus 1. Socket ; is for Cache Accelerator 1. Processor sockets 5 through 8 are on processor bus 2 with socket <...
Page 80 4-12 Compaq ProLiant 8500 Servers Setup and Installation Guide WARNING: To reduce the risk of personal injury from hot surfaces, allow the internal system components to cool before touching them. 3. Loosen the thumbscrew of the middle air baffle and lift the baffle upward to allow access to the Cache Accelerator slots.
Page 81: Sdram Memory
Installing Hardware Options 4-13 5. Align the Cache Accelerator module with the socket closest to installed processors. Install and secure the processor power module by pushing it into the socket. Figure 4-13. Installing the Cache Accelerator 6. If there are more than four processors installed, install a second Cache Accelerator module as in step 5.
Page 82: Adding Or Replacing Memory
4-14 Compaq ProLiant 8500 Servers Setup and Installation Guide CAUTION: Use only Compaq DIMMs. DIMMs from other sources may affect data integrity adversely. To install more memory, refer to one of the following installation sources: For a detailed text and illustrated procedure, refer to the documentation provided with the DIMM option kit.
Page 83 Installing Hardware Options 4-15 3. Remove the memory board by rotating the ejectors outward 1 and pulling the board out 2. 4. Place the memory expansion board, components facing up, on a flat surface. Figure 4-14. Removing the memory board NOTE: The memory board is part of the system interconnect scheme and must be seated properly for server start up.
Page 84 4-16 Compaq ProLiant 8500 Servers Setup and Installation Guide 7. Insert each DIMM 2 directly into the socket until the module is properly seated. Figure 4-15. Installing DIMM memory module in memory board 8. Secure the DIMM by closing the socket latches 3.
Page 85: Mass Storage
The following sections provide overviews for installing hard disk drives, CD-ROM drives, and external storage devices. The ProLiant 8500 supports up to four 1-inch, Ultra2, Single Connector Assembly (SCA), hot-plug hard drives. The server ships with the media module occupied by a diskette drive and slimline CD-ROM drive.
Page 86 4-18 Compaq ProLiant 8500 Servers Setup and Installation Guide The following illustration shows the media module populated with four 1-inch hard drives 1-4, IMD 5, a diskette drive 6, and a CD-ROM drive 7 installed. Figure 4-17. Four 1-inch hot-plug hard drives installed in media module...
Page 87: Scsi Hard Drive Installation Guidelines
Installing Hardware Options 4-19 SCSI Hard Drive Installation Guidelines The following guidelines should be noted when adding SCSI hard drives: A maximum of four 1-inch, Ultra2 SCSI drives may be added in the media module. If only one SCSI hard drive is used, it should be installed in the lowest numbered bay.
Page 88: Installing A Hot Plug Scsi Hard Disk Drive
4-20 Compaq ProLiant 8500 Servers Setup and Installation Guide Installing a Hot Plug SCSI Hard Disk Drive CAUTION: Before adding or removing any hot-plug SCSI drives, consult your operating system instructions. Failure to do so could result in loss of data or damage to equipment.
Page 89 Installing Hardware Options 4-21 3. Insert the hot-plug drive into the empty drive bay, pushing until securely seated 1. 4. Secure the hot-plug drive in the drive cage by swinging the ejector lever inward 2, as shown below. Figure 4-19. Installing a SCSI hard drive CAUTION: Before removing any hot-plug hard drive, read the important guidelines in the following two sections.
Page 90 4-22 Compaq ProLiant 8500 Servers Setup and Installation Guide Hot-Plug SCSI Hard Drive Indicators The Hot-Plug SCSI hard drives used with ProLiant 8500 servers have three LEDs that indicator the status of the drives: 1 - Activity, 2 - Power/Online, and 3 - Fault.
Page 91 Installing Hardware Options 4-23 Important Guidelines About Replacing Hot-Plug SCSI Hard Drives When replacing hot-plug hard drives in a fault-tolerant configuration, these guidelines must be followed: Never remove a hot-plug drive if the Online LED is green. Replace a hot-plug hard drive only when the drive’s Fault LED is amber, indicating a failure.
Page 92: External Storage Devices
Online LED will flash green. The LED will continue to flash until the drive is completely restored. External Storage Devices Optional mass storage devices can be connected to the ProLiant 8500 by installing a PCI expansion board with an external connector. For information on attaching to PCI expansion boards refer to the ProLiant SCSI Cabling Guide.
Page 93: I/O Expansion Boards
Server Setup and Management pack shipped with your server to run the System Configuration Utility. I/O Expansion Boards The ProLiant 8500 server supports PCI Hot Plug. PCI Hot Plug and the server’s operating system work together to allow the following hot-plug actions:...
Page 94: Locating The I/O Expansion Slots
4-26 Compaq ProLiant 8500 Servers Setup and Installation Guide Locating the I/O Expansion Slots The I/O expansion slots are located in the I/O Module, and are accessed by sliding the server out of the rack and opening the top access panel as described in Chapter 3, “Server Operation.”...
Page 95: Pci Hot Plug Leds
Installing Hardware Options 4-27 PCI Hot Plug LEDs The PCI Hot Plug amber LED 1 and green LED 2 indicators (shown in the following figure for one slot) provide a visual reference of the status of each slot. The LEDs are viewed from the rear of the server or by opening the top access panel.
Page 96: Pci Hot Plug Operating System Support
PCI Hot Plug Operating System Support Software support is an integral part of PCI Hot Plug. Compaq, in partnership with Microsoft, Novell, and SCO, has developed PCI Hot Plug software support for each operating system.
Page 97: Plug Slots
Compaq Remote Monitor service (CPQRCMC), the Compaq Systems Management driver (SYSMGMT.SYS), and hot-plug aware drivers. The Compaq PCI Hot Plug Utility allows you to monitor and control PCI Hot Plug slots. You can accomplish the following tasks: View the current power and fault status of all PCI Hot Plug slots in the system.
Page 98 Installing PCI Support Compaq Support Software for Microsoft Windows NT 4.0 (NT SSD), version 2.0 or later, contains all the software components to support Compaq PCI Hot Plug. Included on the NT SSD are hot-plug aware device drivers, such as Compaq NC 3131 Controllers and the Smart Array 3200 Controller.
Page 99 Other boards Installation tools Installing PCI Support Compaq provides PCI Hot Plug support for NetWare via the Novell Software Support Diskette. For more information, refer to the PCI Hot Plug Administration Guide on the Compaq Systems Reference Library CD, the NetWare online documentation, or the Compaq White Paper “Hot Plug Expansion on Compaq Servers in...
Page 100 4-32 Compaq ProLiant 8500 Servers Setup and Installation Guide SCO UnixWare Supported PCI Functionality Compaq support of PCI Hot Plug under UnixWare 7.01 provides hot- replacement, hot-upgrade, and hot-addition for a variety of boards. You can eliminate downtime when you replace faulty adapters, upgrade your systems, and dynamically add new adapters.
Page 101: Supported I/O Expansion Boards
Administration Guide on the Systems Reference Library CD. Supported I/O Expansion Boards The I/O board of the ProLiant 8500 has eleven PCI Hot Plug expansion slots. These slots are distributed among three PCI buses as shown in Table 4-4. The ProLiant 8500 server is shipped with a Network Interface Controller (NIC) in a slot on bus 1.
Page 102: Bus Distribution
4-34 Compaq ProLiant 8500 Servers Setup and Installation Guide Bus Distribution The I/O board in the ProLiant 8500 uses two 33-MHz PCI buses and one 66- MHz bus. The following figure and table identifies the PCI expansion slots associated with each of the three PCI buses. Bus balancing is not required.
Page 103 8. Run the System Configuration Utility as described in Chapter 6, “Server Configuration.” Hot Plug Expansion Boards The PCI slots of the ProLiant 8500 I/O board are Hot Plug capable and support a variety of industry-standard expansion boards. For details, see “Supported I/O Expansion Boards” later in this chapter.
Page 104 4-36 Compaq ProLiant 8500 Servers Setup and Installation Guide 3. Press on the top 1 of the appropriate expansion slot release lever and open the lever toward the rear 2 of the expansion slot. 4. Remove the expansion slot cover 3.
Page 105 Installing Hardware Options 4-37 8. Close the expansion slot release lever from the rear of the unit to secure the board. Make sure that the lever latches into the closed position. 9. To keep the full-length expansion boards fully seated, be sure the L-shaped slot keeper tabs on the plastic expansion board guide are positioned over the forward end of the expansion board.
Page 106: Removing Or Replacing A Pci Hot Plug Expansion Board
4-38 Compaq ProLiant 8500 Servers Setup and Installation Guide Removing or Replacing a PCI Hot Plug Expansion Board 1. Open the top access door. 2. Use the PCI Hot Plug Button or software application to turn power off to the slot. The green LED will flash during the power down transition and will turn off when power down is complete.
Page 107: Replacing Hot Plug Fans
Installing Hardware Options 4-39 Replacing Hot Plug Fans The ProLiant 8500 server ships with two hot-plug fans. Fan 1 is closest to the rear of the server. Each fan has LEDs that indicate the status of the fan as follows:...
Page 108 4-40 Compaq ProLiant 8500 Servers Setup and Installation Guide 1. Open the top access door. 2. Press the locking latches in 1 and lift the failed hot-plug fan (either 1 or 2) out of the I/O Module 2. Figure 4-30. Removing hot-plug I/O Fan 2 3.
Page 109: Scsi Setup
Chapter SCSI Setup This chapter describes the features and set up of the ProLiant 8500 server Integrated Smart Array Controller (Ultra2 support) . Features The ProLiant 8500 Dual Channel Integrated Smart Array Controller is a dual Ultra2 SCSI array controller. Both channels support Low Voltage Differential (LVD) SCSI devices.
Page 110 If you wish to use a SCSI controller other than the integrated controller for the internal hard drives, you can bypass the internal controller using the Integrated Array Bypass Kit and an optional controller such as the Compaq 3200 Array Controller. See the following section, “Installing the Integrated Array Bypass”...
Page 111: Installing The Integrated Array Bypass
SCSI Setup 5-3 Installing the Integrated Array Bypass This document describes the installation of the Compaq ProLiant 8500 Integrated Array Bypass kit. Use this kit if you want to bypass the Integrated Smart Array Controller (Ultra2 support) and use an optional controller such as the Compaq 3200 Array Controller.
Page 112 5-4 Compaq ProLiant 8500 Servers Setup and Installation Guide 5. Remove the Array Enabler Board as shown in the following figure. Figure 5-2. Removing the Array Enabler Board 6. Install the Integrated Array assembly as shown in the following figure.
Page 113 SCSI Setup 5-5 7. Install the optional SCSI controller board as shown in the following figure. Figure 5-4. Installing the SCSI controller board 8. Connect the Integrated Array Bypass assembly cable to the optional array controller board as shown in the following figure. Figure 5-5.
Page 114: Option Rom-Based Array Configuration Utility
5-6 Compaq ProLiant 8500 Servers Setup and Installation Guide Option ROM-Based Array Configuration Utility The Option ROM-based Array Configuration Utility allows you to setup a simple configuration during Power-On Self-Test (POST). During POST the configuration state of the internal SCSI drives is detected. If either of the following conditions exist, the initial start screen will be displayed.
Page 115: Array Configuration Utility
SCSI Setup 5-7 Array Configuration Utility The Compaq Array Configuration Utility (ACU) is an easy to use graphical configuration utility to help you set up and change drive array configurations. It can be used to configure the standard internal drive controller as well as any option controller boards that you install.
Page 116: Starting The Compaq Array Configuration Utility
Starting the Compaq Array Configuration Utility The Compaq ProLiant 8500 server is shipped with the Array Configuration Utility (ACU) on the SmartStart and Support Software CD. You would normally start the utility as described in the following procedure. If, for any reason, you can not start the utility as described here, the utility is available in a variety of locations as described in a section titled “Alternate Sources of the...
Page 117: Capacity Extension
SCSI Setup 5-9 Capacity Extension Logical drive extension allows you to increase the size of existing logical drives without disturbing the data on those logical drives. If an existing logical drive is full of data, you can extend the logical drive when there is free space on the array.
Page 118: Raid Level And Stripe Size Migration
Error and warning messages include instructions to correct configurations. If a warning message indicates “Internal Error Has Occurred” and cites an error code number, the problem requires assistance from Compaq technical support. See “About This Guide” at the beginning of this book for technical support phone numbers.
Page 119: Smartstart And Support Software Cd
SCSI Setup 5-11 NetWare The Compaq Array Configuration Utility for NetWare (CPQONLIN.NLM), is available on the NetWare Support Software Diskettes (NSSD) in the \DRV_ARRY directory. Generate the NSSD diskettes using the Diskette Builder feature in SmartStart. The NSSD diskettes have an ARRAY.RDM readme file to access instructions on loading and using CPQONLIN.NLM.
Page 120: Server Configuration
CD, refer to the Server Setup and Management pack. The first time the server is configured, the SmartStart program automatically creates a system partition and installs the Compaq System Configuration Utility and other Compaq utilities in that partition. NOTE: Until you run the System Configuration program, an information message indicating that you are running with a default configuration will occur each time you boot the system.
Page 121 To configure the system and load the operating system, refer to the SmartStart documentation provided in the Server Setup and Management pack shipped with your server. To manage the system, refer to the Compaq Management CD provided in the Server Setup and Management pack shipped with your server.
Page 122: Integrated Management Log
Repaired—indicates that corrective action has been taken. Caution—indicates a non-fatal error condition. Critical—indicates a component failure. The Integrated Management Log requires Compaq Operating System- dependent drivers for full support. Refer to the Compaq Support Software CD for instructions on installing the appropriate drivers.
Page 123: Multiple Ways Of Viewing The Log
From on-line operating system utilities NOTE: You can only view the event list on the Integrated Management Display; you cannot print it. Also, events are shown in a shorter form on the display than in Compaq Insight Manager. Integrated Management Display The Compaq Integrated Management Display (IMD) is an integrated, 16x4 character display mounted on the front of the server.
Page 124 4. Select Review or Modify Hardware Settings and press Enter. 5. Select Step 3: View or Edit Details and press Enter. 6. Scroll down until you find the section entitled Embedded Compaq IMD Module. 7. Highlight the field that you want to modify. You must press Enter to edit the highlighted item, then type the text for that field.
Page 125: Customizing Management Display Fields
7-4 Compaq ProLiant 8500 Servers Setup and Installation Guide 11. At the server prompt Save the Configuration and Restart the Computer, select OK=Enter. The changes you have entered will not be displayed on the Display Panel until you reboot the computer. Standard Integrated Management Display fields are defined in the section “Navigating the...
Page 126 Integrated Management Log 7-5 Another example might be to put the company name and slogan or goal, such SMITH & ASSOC OVER 1 BILLION IN SALES 1999 Custom Menu Item This is a user-defined field that can be used for customizing your server. This one-line field can hold up to 14 characters.
Page 127 7-6 Compaq ProLiant 8500 Servers Setup and Installation Guide Administrator Information Name This field contains the name of the system administrator. Enter up to 2 lines of no more than 14 characters each. Phone Number This field contains the phone number of the system administrator. Enter up to 2 lines of no more than 14 characters each.
Page 128: Standard Integrated Management Display Fields
Integrated Management Log 7-7 Other This is a user-defined field. You can enter any additional service information. An example might be to enter service contract number. Enter up to 2 lines of no more than 14 characters each. For example, you might enter server history information such as: SERVICE CONTRACT 1C2002...
Page 129: Navigating The Menus
Press the Up arrow to increase the contrast, and press the Down arrow to decrease the contrast. Navigating the Menus The Compaq Integrated Management Display is menu-driven and easy to use. This section provides information on how to navigate and use the menus. Normal Run-time Behavior After configuring the display and rebooting the server, a series of server POST (Power-On Self-Test) operations appears.
Page 130: Display Symbols
Integrated Management Log 7-9 Display Symbols There are three different display symbols used to indicate your options as you scroll through the menus. These symbols are the Up, Down, and Selector arrows. Table 7-1 Integrated Management Display Symbols Type of Symbol Meaning Symbol...
Page 131: Navigation
7-10 Compaq ProLiant 8500 Servers Setup and Installation Guide Navigation To navigate through the menus, use the four buttons shown in the Figure 7-2. The Down and Up arrow keys (and ) allow you to move through the menu screens and choose menu items. The right button () acts as an Enter key and allows you to travel down through the menus.
Page 132: System Behavior With Error Events
Integrated Management Log 7-11 System Behavior with Error Events After system POST, if there is an F1 error condition the IMD flashes the message: LCD-013.EPS !ALERT! Press Any Key to View New Events Figure 7-3. New event message At this point, you must scroll through each screen of the event information menu before the IMD will allow you to move on to other menu choices.
Page 133 7-12 Compaq ProLiant 8500 Servers Setup and Installation Guide Operating System Other Administrator Name Phone Pager Other Service Name Phone Pager Other Custom Menu Item (if entered) Custom Menu Screen (if entered) System Information ROM Date Bootblock Date Memory Processors...
Page 134: Compaq Insight Manager
Integrated Management Log 7-13 Compaq Insight Manager Compaq Insight Manager is a server management tool capable of in-depth fault, configuration, and performance monitoring of hundreds of Compaq servers from a single management console. System parameters that are monitored describe the status of all key server components.
Page 135: Compaq Survey Utility
7-14 Compaq ProLiant 8500 Servers Setup and Installation Guide Compaq Survey Utility The Compaq Survey Utility is a serviceability tool available for Windows NT and Novell NetWare that delivers online configuration capture and comparison to maximize server availability. It is available on the Compaq Management CD in the SmartStart package, or on the Compaq website at www.compaq.com.
Page 136: Initial Startup And Troubleshooting
If the System LED blinks once every 10-20 seconds, the system is trying to start, but may have a short. Refer to the “System Short” section in the Compaq Servers Troubleshooting Guide. 2. Check the power supplies. The following settings indicate that the power switch is on and the power supply is in a “power on”...
Page 137 8-2 Compaq ProLiant 8500 Servers Setup and Installation Guide 4. When the top LED turns solid green, listen for the fans to start. 5. The hard drive LEDs should blink. If the LEDs do not light, verify that the hard drives are fully installed in the system.
Page 138: System Interconnect Status Indicators
I/O panel. System Interconnect Status Indicators To prevent damage to critical system components, the ProLiant 8500 Server will not power up if it senses that certain components are not installed, or are installed incorrectly. The system interconnect status indicators provided with ProLiant 8500 Server provide a closed-loop checking mechanism for verifying proper component mating between critical server components.
Page 139 8-4 Compaq ProLiant 8500 Servers Setup and Installation Guide Figure 8-1. Accessing System Interconnect Status Indicator LEDs Table 8-1 System Interconnect Status Indicators Indicator Component Indicator Component Emergency Shutdown Termination PPM Processor 8 Memory Processor 7 Processor/Memory Module Processor 6...
Page 140: Running System Diagnostics
This test does require less time than the Automatic Diagnostics Automatic Diagnostics runs a complete set of system tests. This test could require several hours. If errors occur, refer to the “Diagnostics Tools” chapter of the Compaq Servers Troubleshooting Guide for details on other diagnostic options.
Page 141: Regulatory Compliance Notices
Numbers For the purpose of regulatory compliance certifications and identification, your Compaq ProLiant 8500 server is assigned a Compaq Series Number. The Compaq Series number for this product is: Series ES2000. The Compaq ProLiant 8500 server Series Number can be found on the Regulatory Compliance label, along with the required approval markings and information.
Page 142: Class A Equipment
A-2 Compaq ProLiant 8500 Servers Setup and Installation Guide Class B devices are those that may reasonably be expected to be installed in a residential environment (i.e., personal computers). The FCC requires devices in both classes to bear a label indicating the interference potential of the device as well as additional operating instructions for the user.
Page 143: Modifications
Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Compaq Computer Corporation may void the user's authority to operate the equipment. Cables Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods in order to maintain compliance with FCC Rules and Regulations.
Page 144: European Union Notice
A-4 Compaq ProLiant 8500 Servers Setup and Installation Guide European Union Notice Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following...
Page 145: Laser Devices
Regulatory Compliance Notices A-5 Laser Devices All Compaq systems equipped with a laser device comply with safety standards, including International Electrotechnical Commission (IEC) 825. With specific regard to the laser, the equipment complies with laser product performance standards set by government agencies as a Class 1 laser product.
Page 146: Laser Product Label
A-6 Compaq ProLiant 8500 Servers Setup and Installation Guide Laser Product Label The following label or equivalent is located on the surface of the Compaq supplied laser device. This label indicates that the product is classified as a CLASS 1 LASER PRODUCT.
Page 147: Battery Replacement Notice
Vanadium Pentoxide, or an alkaline internal battery or battery pack. There is a danger of explosion and risk of personal injury if the battery is incorrectly replaced or mistreated. Replacement is to be done by a Compaq Authorized Service Provider using the Compaq spare designated for this product. For more information about battery replacement or proper disposal, contact your Compaq Authorized Reseller or your Authorized Service Provider.
Page 148: Electrostatic Discharge
Appendix Electrostatic Discharge To prevent damaging the system, be aware of the precautions you need to follow when setting up the system or handling parts. A discharge of static electricity from a finger or other conductor may damage system boards or other static-sensitive devices.
Page 149: Grounding Methods
B-2 Compaq ProLiant 8500 Servers Setup and Installation Guide Grounding Methods There are several methods for grounding. Use one or more of the following methods when handling or installing electrostatic-sensitive parts: Use a wrist strap connected by a ground cord to a grounded workstation or computer chassis.
Page 150: Power Cord Set Requirements
Power cord sets for use in other countries must meet the requirements of the country where you use the server. For more information on power cord set requirements, contact your Authorized Compaq Dealer. General Requirements The requirements listed below are applicable to all countries: The length of the power cord must be at least 6.0 feet (1.8 m) and a...
Page 151: Country-Specific Requirements
C-2 Compaq ProLiant 8500 Servers Setup and Installation Guide Country-Specific Requirements Use the following table to identify the appropriate accredited agency in your country. Table C-1 Power Cord Set Requirements - By Country Country Accredited Agency Applicable Note Numbers Argentina...
Page 152 Power Cord Set Requirements C-3 Table C-1 Power Cord Set Requirements - By Country continued Country Accredited Agency Applicable Note Numbers South Africa SABS Sweden SEMKO Switzerland United Kingdom United States Notes: Flexible cord must be <HAR> Type HO5VV-F, 3-conductor, 1.0 mm conductor size.
Page 153: Server Specifications
Appendix Server Specifications Table D-1 Compaq ProLiant 8500 Server Specifications Dimensions Height 12.0 in 30.5 cm Depth 27.0 in 68.5 cm Width 17.5 in 44.5 cm Weight (no drives and two power supplies) 111 lb 50.5 kg Input Requirements (per power supply)
Page 154 Index AC cord retention clip 2-27 battery recycling or disposal A-7 access panel 3-6 battery replacement warnings A-7 ACU See Array Configuration blanking panels 4-19 Utility boot administrative information 1-13 block 1-8 administrator password 1-13 default configuration 6-1 airflow straps, using B-2 blanking panel 2-6 System Configuration rack 2-6...
Page 155 2 Compaq ProLiant 8500 Servers Setup and Installation Guide Canadian Notice (Avis connectors Canadien) A-3 external SCSI 2-26 capacity expansion, defined 5-8 keyboard 2-26 capacity extension mouse 2-26 defined 5-9 parallel port 2-26 supported by 5-9 rear panel 2-26 cautions...
Page 156 Index 3 DIMMs European Union Notice A-4 accessing 3-6 event description 1-13 expansion 4-13 Insight Manager 7-2 installing 4-13 expansion boards, non-hot supported 1-4 plug 4-25 upgrades 1-4 expansion slots See I/O expansion disconnecting power 2-27, 3-2 slots disk controller features 1-5 external SCSI connector 2-26 diskette boot password override 1-14...
Page 157 4 Compaq ProLiant 8500 Servers Setup and Installation Guide grounding Hot Plug methods B-2 SCO UNIX 4-32 receptacles 2-4 slots, 34 bit 1-4 strap specifications B-2 slots, 64-bit 1-4 straps B-2 technology brief 4-30, 4-31 suggested equipment for B-2 utility 1-4, 4-29...
Page 158 Index 5 illustrated indicators new event message 7-11 Interconnect Status 3-4 PCI expansion board 4-36 power supplies 4-4 PCI Hot Plug Button 4-37 System Interconnect PCI Hot Plug LED Status 8-3 indicators 4-27 Insight Manager processor board layout 4-6 IMD 7-13 processor power module 4-9 information 1-12 processor processor power...
Page 159 6 Compaq ProLiant 8500 Servers Setup and Installation Guide interfaces locating CPQRCMC 4-29 cache accelerator sockets 4-11 parallel control 1-13 I/O expansion slots 4-26 ROMPaq 1-9 memory socket 4-6 standard 1-6 processor slots 4-6 internal hot plug drive bays Log, Integrated Management...
Page 160 Index 7 modules Novell I/O 1-2, 3-7 Event Bus (NEB) 4-31 Media 1-2, 3-11 Open Data-Link Processor and Interface 4-31 Memory 1-2, 3-9 Software Support monitor Diskette 4-31 connecting 2-2 NT See Windows NT mounting bracket 2-14, 2-19 NT SSD 4-30 mouse NWPA 4-31 connecting 2-2...
Page 161 8 Compaq ProLiant 8500 Servers Setup and Installation Guide overview power system interconnect 3-4 supply indicators, green/amber Windows NT 4-29 alternating 3-3 supply indicators, normal operation 3-3 supply, indicators 3-3 panel power cord set opening 3-7 agency approval C-1 top access 3-6...
Page 162 Index 9 processors requirements power modules, airflow 2-6 accessing 3-10 Hot Plug 4-25 sockets, accessing 3-6 memory 4-13 power 2-2 space 2-3 temperature 2-2 QuickLock 1-13 tools 2-7 retention clip 2-27 RJ-45 connectors 1-6 rack corrupted 1-8 airflow 2-6 faulty 1-8 clearance 2-6 flashing 1-9 maximum internal...
Page 163 10 Compaq ProLiant 8500 Servers Setup and Installation Guide server Support Software for Unix See registration 1-14 Server Setup and Management Survey Utility 7-2, 7-14 pack 2-2, 6-2 switch and jumper settings 1-10 Servers Troubleshooting switches Guide 7-14 configuration 3-6...
Page 164 2-5 unpacking 2-7 tape drive, accessing 3-12 unviewed events, IMD 7-11 technical support upgrades Compaq website xiii DIMMs 1-4 telephone numbers xiii flash ROMs 1-14 technician notes xi options 4-1 technology brief, Hot Plug 4-30 PCI exapansion boards 1-4...
Page 165 12 Compaq ProLiant 8500 Servers Setup and Installation Guide utilities warnings ROMPaq 1-8 improper repairs xi Survey 7-14 personal injury ix, xi System Configuration See power cord grounding System Configuration plug 3-2 utility power cords 3-2 Windows NT 1-11 power supplies 2-27...

Compaq ProLiant 8500 Setup And Installation Manual

About this Guide

Chapter 1 Introduction

Introduction

Chapter 2 Server Installation

Server Installation

Chapter 3 Server Operation

Chapter 4 Installing Hardware Options

Chapter 5 SCSI Setup

Chapter 6 Server Configuration

Chapter 7 Integrated Management Log

Chapter 8 Initial Startup and Troubleshooting

Appendix A Regulatory Compliance Notices

Appendix B Electrostatic Discharge

Appendix C Power Cord Set Requirements

Appendix D

Server Specifications

Quick Links

Need help?

Questions and answers

Related Manuals for Compaq ProLiant 8500

Summary of Contents for Compaq ProLiant 8500

Table of Contents
