Compaq ProLiant 8500 Server Technology
. .
. .
. .
. .
. .
This technology brief describes the high-performance, high-availability, storage, and
. .
management technologies built into the Compaq ProLiant 8500 server. The high-
. .
. .
performance technologies include a new 8-way system architecture driven by the
. .
. .
Profusion chipset codeveloped by Compaq, Intel, and Corollary, as well as Intel's
. .
Pentium III Xeon processors. In addition, new disk drive technology and a new
. .
. .
integrated array controller optimize the ProLiant 8500 server's internal storage for
. .
operating system and boot support while allowing maximum external storage capacity.
. .
. .
. .
The high-availability technologies include PCI Hot Plug technology; redundant hot-plug
. .
power supplies, drives, and fans; redundant processor power modules; and auto
. .
. .
processor bus recovery. The ProLiant 8500 server uses a highly modular design that
. .
. .
allows easy access to components, thus reducing downtime for service and upgrades.
. .
The ProLiant 8500 server also incorporates key management technologies, such as the
. .
. .
Integrated Remote Console, Integrated Management Display, Remote-flash Redundant
. .
. .
ROM, and auto-default ROM configuration, that further enhance availability.
. .
. .
The intended audience for this paper is engineers and system administrators familiar
. .
. .
with existing Compaq technology and servers. For those less familiar with Compaq
. .
technology, please see the related technology briefs referenced in this document. For
. .
. .
more information about the ProLiant 8500 server, see the complete list of features at
. .
. .
http://www.compaq.com/products/servers/ProLiant8500/quickspecs.html.
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
. .
