Technical Specifications
48

Function Description

Input and output scaling capability.
Working of the analogue outputs (y) versus input variables (x)
Figure A
The sign of measured quant-
ity and output quantity re-
mains the same. The output
quantity is proportional to the
measured quantity.
Figure B
The sign of measured quant-
ity and output quantity
changes simultaneously. The
output quantity is proportion-
al to the measured quantity.
Figure C
The sign of measured quant-
ity and output quantity re-
mains the same. On the
range X0...X1, the output
quantity is zero. The range
X1...X2 is delineated on the
entire output range Y0 =
Y1...Y2 and thus presented in
strongly expanded form.

Insulation between inputs and outputs

Meas. /digital Relay
inputs output
Meas. /digital
-
inputs
Relay output 4kV 4kV (*)
4kV
Open collector
Analogue out.
2kV
10V, 20mA
Analogue out.
2kV
±5mA
AR1034 4kV
AR2040 2kV
AR1039 4kV
4kV
90-260VAC/DC
4kV
18-60VAC/DC
NOTE: In case of fault of first insulation the current from the measuring inputs to the ground is lower than 2 mA.
(*) The given insulation is granted among outputs plugged in different slots. The modules equipped with two or four outputs have
therefore non insulation among the outputs. (**) Insulation between the 2 outputs of the same module is 200V for 1 min.
0 50 A
0 10 mA
-100 kW 0
-5 mA 0
80 V 100 V
0 5 mA
Open
Analogue out.
colllector 10V, 20mA
4kV 4kV 2kV
4kV 4kV
4kV 4kV (*) 4kV
4kV 4kV 4kV (*)
4kV 4kV 4kV
4kV 4kV 4kV
4kV 4kV 4kV
4kV 4kV 4kV
4kV 4kV 4kV
4kV 4kV 4kV
Figure D
The sign of measured quant-
ity and output quantity re-
mains the same. With the
measured quantity being
zero, the output quantity
already has the value
Y1 = 0.2 Y2.
Live zero output.
100 A
20 mA
Figure E
The sign of the measured
quantity changes but the one
of the output quantity
remains the same. The out-
put quantity steadily increas-
es from value X1 to value X2
of the measured quantity.
100 kW
+ 5 mA
Figure F
The sign of the measured
quantity remains the same,
the one of the output quantity
changes as the measured
quantity leaves range X0...X1
and passes to range X1...X2
and vice versa.
120 V
10 mA
Analogue out.
AR1034
±5mA
2kV 4kV
4kV 4kV
4kV 4kV
4kV 4kV
200V (**) 4kV
4kV -
4kV -
4kV 4kV
4kV 4kV
4kV 4kV
WM5-96 Instruction Manual
0
4
-100 kW
0
0
- 5 mA
AR2040 AR1039 90-260VAC/DC 18-60VAC/DC
2kV 4kV 4kV
4kV 4kV 4kV
4kV 4kV 4kV
4kV 4kV 4kV
4kV 4kV 4kV
- 4kV 4kV
- 4kV 4kV
4kV - 4kV
4kV 4kV -
4kV 4kV -
50 A 100 A
12 mA 20 mA
0 100 kW
10 mA 20 mA
50 A 100 A
0 + 5 mA
4kV
4kV
4kV
4kV
4kV
4kV
4kV
4kV
-
-
