Wiring diagrams
42

Power supply, analogue and digital output modules

AP1020.
A1 A2
AP1021.
Power supply.
F
F= 1.25 A T
N -
+
L
AO1058.
1 relay output

Digital inputs

AQ1042.
Connection by means of
NPN transistors.

RS485 serial port (AR1034 9600bps, AR2040 115200bps)

T
a
T
a
AO1035.
2 relay outputs
AQ1042.
Connection by means of
PNP transistors.
b
b
AO2050.
2 analogue outputs
0-20mA DC.
Connection by means of
2-wire connection. Other WM5-96
nected in parallel (b). Serial RS485-RS232 converter.
Termination of the serial port (T): it's carried out only on the last
instrument of the network, by means of a jumper between (Rx+) and
(T).
4-wire connection. Other WM5-96
lected in parallel (b). Serial RS485-RS232 converter.
Terminatio of the serial port (T): it is carried out only on the last
instrument of the network, by means of a jumper between (Rx+) and
(T).
WM5-96 Instruction Manual
AO2052.
2 analogue outputs
-5/+5mA DC.
AO1037. 4 open collector outputs. This wiring
diagram is also valid for the open collector mod-
ules with 1 or 2 outputs. The load resistances
(Rc) must be designed so that the close contact
current is lower than 100mA; the VDC voltage
must be lower than or equal to 30VDC.
AQ1042.
contacts.
(a) provided with RS485 are con-
(a) provided with RS485 are col-
AO2051.
2 analogue outputs
10V DC.
AQ1038.
Connection by
means of contacts.
