WM5-96 Instruction Manual

Software functions

Password
1st level
2nd level
System selection
System 1
System 2, unbalanced
System 3, balanced
System 3, unbalanced
Transformer ratio
Filters
Filter operating range
Filtering coefficient
Filter action
Alarms
Working mode

Wm5Soft parameter programming and variable reading software

Wm5Soft
Technical Specifications
Numeric code of max 4
digits from 0 to 1000;
2 protection levels of
the programming data
Password "0": no protection
Password from 1 to 1000:
all data are protected.
1-phase (2 wires)
2-phase (3 wires)
3-phase (3 wires+1CT)
3-phase (3 wires)
3-phase (4 wires)
CT up to 60 kA (6000 max)
VT (PT) up to 600 kV
(6000 max)
0.1 to 100% of the input
electrical scale.
1 to 255
Display, alarms, serial outputs
(fundamental variables:
V, A, W and their derived ones).
"OR" or "AND" or
"OR+AND" functions (see
"Alarm parameter and
logic" page).
Freely programmable on up
to 16 alarms. The alarms
can be connected to any
variables available in the
table "List of the variables
that can be connected to"
Multi-language software
(Italian, English, French,
German, Spanish) for
variable reading,
instrument calibration and
parameters programming.
The program runs under
Windows XP/Vista
Working mode
Three different working
modes can be selected:
- management of local
Reset
Data stamping
Type of data
Number of events
Data management type
Data storage type
Displaying
Energy meters
Stored events
Display language
Data Storing
Data Transfer
45
By means of the key-pad or
of the configuration software,
it is possible to reset the
following data:
- all the min, max, dmd,
dmd-max values.
- total and partial counters.
- latch alarms.
- all the events.
Alarm, min, max, digital
input status, digital output
status as remote control,
resets. All events are stored
with date (dd:MM:yy) and
hour (hh:mm:ss) reference
Up to 10.000
FIFO
Data flash
4 variables per page
1 page that can be laid out
by the user
Up to 36 pages
Up to 28 pages depending
on the selected tariff mode.
Displaying of the consumed
energy of the previous 12
months.
10,000 events.
Selectable:
English, Italian, French,
German, Spanish
RS232 (MODBUS);
- management of local
optical port (MODBUS);
- management of a local
RS485 network (MODBUS);
In pre-formatted XLS files
(Excel data base).
Manual or automatic at
programmable timings.
