WM5-96 Instruction Manual

General Specifications

Operating
temperature
Limit range of operating temp.
Storage
temperature
Installation category
Pollution degree
Altitude
Insulation reference voltage
Dielectric strength
Noise Rejection
CMRR
EMC
Emissions

Supply Specifications

AC/DC voltage

Revenue Approval Settings

• The access to the programming parameters via front key pad and/or serial communication ports is locked.
• The front key pad (up and down keys) allows the displaying of the variables only, while the communication ports allows the
transmission of the variables only.
• A proper "instrument settings" form must be filled up by the user before equipment supplying.
• WM5-96 is supplied with the desired modules plugged and sealed in the proper slots.
• WM5-96 fulfils: the ANSI/IEEE C12.20-1998 requirements;
the CAN3-C17-M84 requirements;
and can be certified according to:
C12.20-1998, class 0.5 (independent labs);
AE-0924 Industry Canada Approval.
Technical Specifications
-10° to +45°C (14° to 113°F)
(R.H. < 90% non-condensing)
-20° to +55°C (-4° to 131°F)
(R.H. <90% non-condensing)
-30° to +60°C (-22° to 140°F)
(R.H. < 90% non-condensing)
III
2
up to 2000m (6560 feet) above
sea-level
300 V to ground (AV5 input)
RMS
4kVAC (for 1 min)
RMS
100 dB, 48 to 62 Hz
EN61000-6-3, EN60688
residential environment,
commerce and light industry
ANSI/IEEE C37.90-1989
(surge, withstand and fast
transient test)
90 to 260V (standard)
18 to 60V (on request)
Pulse voltage (1.2/50µs)
Safety standards
Measurement standards
ANSI C12.20, ANSI C12.1
Approvals
Connections 5(6) A
Housing
Dimensions
Material
Protection degree
Weight
Power consumption
47
EN61000-4-5
IEC60664, IEC61010-1
EN60664, EN61010-1
IEC60688, EN60688,
EN62053-22, EN62053-23,
CE, cURus and CSA
Screw-type
2
max. 2.5 mm wires
2
(2x 1.5mm );
max screw tightening
torque: 0.5Nm
96x96x140 mm
ABS,
self-extinguishing: UL 94 V-0
Front: IP65 / NEMA 4x
Approx. 600 g
(packing included)
≤ 30VA/12W (90 to 260V)
≤ 20VA/12W (18 to 60V)
