Power supply specifications
90 to 260 VDC/VAC;18 to 60VDC/VAC;
24 VAC -15%+10% 50-60Hz; 48 VAC -15%+10% 50-60Hz;
115VAC -15%+10% 50-60Hz; 230 VAC -15%+10% 50-60Hz
General features
Operating temperature:
0 to +50°C (32 to 122°F) (H.R. < 90% non condensing)
Storage temperature:
-10 to +60°C (14 to 140°F) (HR. < 90% non-condensing)
Installation category: Cat. III (IEC 664)
Key-pad lock: by means of switch placed behind the dis-
play or by means of contact (if module 3 - input contacts -
is present).
Insulation: 4000 V
Dielectric strength: 4000 V
EMC
Emissions: EN50082-1 (class A) residential, commercial
and light industry environment. Immunity: EN 61000-6-2
(class A) industrial environment.
Other standards
Safety: IEC 61010-1, EN 61010-1
Product: IEC 60688-1, EN 60688-1
Approvals: CE
5(6)A connections: screw-type, max. section 2.5 mm
2
(2 x 1.5mm )
Housing: Dimensions: 96x96x140 mm
Material: ABS, NORYL, PC (front); self-extinguishing: UL 94 V-0
Protection degree: Front: IP65
Connections: IP20
Weight: approx. 400 g (packing included)
Electrical diagrams
35
Technical features
between inputs/outputs and ground
RMS
36
for 1 minute
RMS
2
