What is ASY
The ASY variable allows the user to control the symmetry of
the delta voltages (for systems without neutral) and star volt-
ages (for systems with neutral). The variable is calculated
according to the following formula:
Where: Vmax is the max. value among VL1-N, VL2-N, VL3-N
Vmin is the min. value among VL1-N, VL2-N, VL3-N
Vavg is the average: (VL1-N, VL2-N, VL3-N)/3
The variable is not displayed by the instrument, but can be
retransmitted by the analogue or RS422 / 485 output and
can be controlled by means of the alarm.

Retransmitted variables

N° Variable 3-ph with
1 V L-N
2 V L-L
3 W
4 var
5 VA
6 PF
7 PF
8 VA dmd
9 W dmd
10 ASY
11 The energy meters as per table on page 17
12 All instantaneous variables (powers, currents, voltages)
Digital Output 2
19
Useful Information
Vmax - Vmin
ASY=
neutral
x
x
x
x
x
x
x
x
x
x
23
*100
Vavg
3-ph with-
out neutral
x
x
x
x
x
x
x
x
x
25
Notes
= system
= system
= system
= system
= system
= system
asymmetry
