CARLO GAVAZZI WM24-96 - PROGRAMMING User Manual page 14

S
S
S
S
VT Ratio
11
Programming
Access to the energy
meters menu
This function allows the user to choose
the parameters for the management of
the energy meters. Choose the function
"COUntEr" by means of the
keys: to confirm the value and enter
the submenu press
the and
scroll all the functions relating to the
energy meters that will be described in
detail below.
The functions of the Energy
Meters submenu.
Choose the desired function by
means of the
S
press to confirm. It's possible
to choose the following combina-
tions:
tot: it enables the combination of
total and partial meters (see page
6).
tot Prd: it enables the combination
of total and partial meters: tariff t1,
t2, t3 and t4 are managed by the
digital inputs (see page 8);
Retransmitt. en. Meters
22
9
13
S
. By means of
keys, it's possible to
and
and
keys,
17
