CARLO GAVAZZI WM24-96 - PROGRAMMING User Manual page 4

INSTALLATION
Operations preliminary to the installation . . . . . . .26
Front panel cut-out . . . . . . . . . . . . . . . . . . . . . . .27
Position of slots and relevant modules . . . . . . . . .28
Connection of optional modules . . . . . . . . . . . . . .31
1-phase electrical diagrams . . . . . . . . . . . . . . . . .34
3-phase electrical diagrams . . . . . . . . . . . . . . . . .34
TECHNICAL FEATURES . . . . . . . . . . . . . . . . . . . . .36
We suggest you to keep the original packing in case it is
necessary to return the instrument to our Technical
Service Department. In order to achieve the best results
with your instrument, we recommend you to read this
instruction manual carefully.
HOW TO USE THE SYMBOLS
Go to the page where the previous main subject
is described.
Go to the page where the next main subject is
described.
Go to the page where the subject written on the
top of the current page starts.
Go to the page where the subject written on the
top of the current page ends.
This symbol indicates a particularly important
subject or information.
This symbol indicates that more details are given
on the current subject.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
2
3
Index
Display "tot -1 .Cn"
7
