3 On the All-In-One toolbar, click and hold the Circle button, and on the
toolset, click any of the Circle buttons. Create new circles in your drawing.
4 When you finish working with circles, delete the entities.
To create a polyline
1 On the All-In-One toolbar, click and hold the Polyline button.
2 On the toolset, drag the pointer until you locate Single Polyline, and then
release the mouse button.
3 In the drawing window, click a point to begin the polyline, and then click
two more points to create a polyline that is shaped like the letter "V".
When you have created your polyline, right-click twice to complete the
line and end the polyline command. Try this a few times to get familiar
with it.
Example of a polyline produced with the Single Polyline option
4 On the All-In-One toolbar, click and hold the Polyline button, and on the
toolset, click any of the Polyline buttons. Experiment with the different
kinds of polylines you can create.
5 When you finish working with polylines, delete the entities.
To create a polygon
1 On the All-In-One toolbar, click the Polygon button.
2 On the toolset, drag the pointer until you locate Rectangle, and then
release the mouse button.
3 In the drawing window, click a point to begin the rectangle, and then click
another point to end the rectangle.
Example of a polygon produced with the Rectangle option
Create Other Simple Entities
|
