Tip During an AutoSketch work session, you can access existing drawings by
clicking File ➤ Open.

Understand the User Interface

The first step in learning how to use AutoSketch is to become familiar with
its user interface.

Drawing Window

Once you choose the type of drawing you want to create, AutoSketch opens
a drawing window. The drawing window in AutoSketch is the space where
you work.
Many drawing windows can be open at one time. Clicking a drawing window
makes it active so that you can work in it. You can make changes in the active
window only. You can resize, minimize, maximize, and close each drawing
window independently.
The following illustration shows the AutoSketch user interface elements in a
drawing window. These elements are listed alphabetically and described after
the illustration.
|
