Toolbar Button name
button
Isometric Left
Isometric Right
Double Grid Size
Halve Grid Size
You can also change settings using the Edit Grid button on the Standard
Tip
toolbar.

Grid Origin

The grid origin is similar to the drawing origin in function and appearance.
However, the grid origin serves as a reference point for grid coordinates only.
By default, the grid origin is located at the drawing coordinates 0,0. You can
move the grid origin of rectangular, circular, or isometric reference grids.

Snap

Using snap, you can draw with real precision by identifying exact points such
as an entity's midpoint, endpoint, or centerpoint. These points are called
snap points because when you click near one, the point is snapped to the
exact point shown.
There are 15 ways to snap to a point in AutoSketch. These correspond with
the 15 snaps you can choose by clicking their buttons on the All-In-One tool-
bar, Snap toolbar, or by typing the letter shown on the button.
Description
Aligns snap and grid lines along 90- and 150-degree
axes.
Aligns snap and grid lines along 90- and 30-degree
axes.
Doubles the current grid size.
Decreases the current grid size by half.
Basic Features and Functionality
|
37
