C H A P T E R 3
Network Configurations
Single Server
Router
Multiple
Servers
Router
Network Configurations
The HP e-Commerce/XML Server Accelerator SA7150 is typically
used with multiple servers although it can support multiple
applications running on separate ports of a single server. In single
server configurations the SA7150 is connected to the network
between the router and the server.
Ideally, the SA7150 is installed in the network in such a way as to
minimize network latency.
HP e-Commerce/XML Server Accelerator SA7150
SA7150 in Single Server Configuration
In the more common multiple server configuration, the SA7150 sits
between the router and the switch. XML traffic is intercepted,
decrypted (if SSL-encrypted), processed, and sent to an XML server.
HP e-Commerce/XML Server
Accelerator SA7150
SA7150 in Multiple Server Configuration
XML Server 1
hub/switch
App1
App 2
App 3
Single Server
XML Server 2
XML Server 3
31
