C H A P T E R 4
Scenario 6—Configuring a Firewall
Firewall
Single SA7150 configured with single server and firewall
Server
Configuration
Scenario 6—Configuring a Firewall
This scenario describes the recommended network configuration to
allow a SA7150 to provide SSL services for a single server that also
serves plain-text HTTP documents. Actual procedures for adjusting
the firewall and server configurations vary widely depending upon
the products used, so the steps outlined here are necessarily
approximations and must be adjusted as required by the particulars of
your environment. Please consult your server and firewall
documentation for additional information.
HP e-Commerce/XML Server Accelerator SA7150
Servers providing both HTTP and HTTPS services typically have
two instances of the Web Server process configured:
One listening on the standard HTTP port of 80, providing
•
unencrypted access to non-sensitive information, and
Another listening on port 443 providing access to SSL encrypted
•
sensitive information.
Port Number
80
443
Connection Type
HTTP
HTTPS
Server
Content Served
Non-sensitive
Sensitive
67
