C H A P T E R 4
Scenario 5—Different Ingress and Egress
Routers
Client
Procedure for
Scenario 5
NOTE: Execute an "arp
–a" (or equivalent
command for your OS) on
the server to display the
MAC address of the
default gateway. This is
the address you should
use.
66
HP e-Commerce/XML Server Accelerator SA7150 User Guide
This scenario describes the configuration of a SA7150 when the
ingress and egress traffic paths are different. This scenario includes:
One or more servers
•
One or more cascaded SA7150s
•
One or more ingress routers
•
One egress router
•
Ingress Router
Egress Router
Installation with Ingress and Egress Routers
1. Configure your SA7150 (as described in any of the previous sce-
narios).
2. Determine the MAC address of the egress router you wish to
route outbound traffic through.
3. At the CLI prompt, enter the default egress router.
HP SA7150> set egress_mac 00:11:22:33:44:55
Egress MAC set to 00:11:22:33:44:55
HP SA7150> config save
Saving configuration to flash...
Configuration saved to flash
HP SA7150>
4. To reverse this process:
HP SA7150> set egress_mac none
HP e-Commerce/XML Server
Accelerator SA7150
Switch
Server
