C H A P T E R 4
62
HP e-Commerce/XML Server Accelerator SA7150 User Guide
5. Use the list map command to view the mapping. (Multiple keys
and certificates can also be imported and each mapped to
individual servers. If you do this, at least one field in the
certificate information—usually the common name—must be
unique.)
HP SA7150> list map
Map
ID KeyID Server IP Port
== ===== ========= ===== ==== ======== =====
1 default Any
2 default 1.1.1.30 443
3 default 1.1.1.31 443
HP SA7150>
6. After you have manually created a mapping, the default mapping
can be deleted. In this case, delete MapID number 1. MapID
number 2 becomes MapID number 1 when the default is deleted.
HP SA7150> delete map 1
HP SA7150> list map
Map
ID KeyID Server IP Port
== ===== ========= ===== ==== ======== =====
1 default 1.1.1.30 443
2 default 1.1.1.31 443
HP SA7150>
To configure a third or fourth web server to operate with the SA7150,
repeat the steps above, specifying a different IP address for each
server.
7. Save the configuration when mapping is completed for the
server(s).
HP SA7150> config save
Saving configuration to flash...
Configuration saved to flash
HP SA7150>
Net Ser Cipher Re-
Port Suites direct Auth
443 80 all(v2+v3) n
80 all(v2+v3) n
80 all(v2+v3) n
Net Ser Cipher Re-
Port Suites direct Auth
80 all(v2+v3) n
80 all(v2+v3) n
Client well
XML form
===== === ====
n n N/A
n n N/A
n n N/A
Client well
XML form
===== === ====
n n N/A
n n N/A
