HP ProLiant DL380 Generation 5 Quickspecs

QuickSpecs
Overview
Front View: Front View: Front View: Front View:
1. Eight sockets for PC2-5300 Fully Buffered DIMMs (DDR2-
667)
2. Hot-plug fans, full redundancy
3. Systems Insight Display
4. Quick release lever for rapid server access
5. Support for eight Small Form Factor hot plug hard drives
bays
6. Front LEDs (show server status) and Unit Identification
button/LED (for easy in rack server identification)
7. Two front USB ports (2 rear USB ports, 1 internal USB port) 7.
8. Intel Xeon Processor (Performance models include two
processors)
9. Hot plug power supply, redundancy option (High
performance models include redundant power supply)
10. Three full-size PCI-E expansion slots in standard expansion
cage (or optional mixed PCI-X/E expansion cage). Two
additional low-profile PCI-E slots embedded on the system
board. Four slots available for use; one consumed by Smart
Array controller (Base and Performance models)
11. Quick removal access panel
What's New What's New What's New What's New
New Intel® Xeon® X5270 Dual-Core processor
At A Glance At A Glance At A Glance At A Glance
DA - 12477 North America — Version 63 — September 23, 2010
HP ProLiant DL380 Generation 5 (G5) HP ProLiant DL380 Generation 5 (G5) HP ProLiant DL380 Generation 5 (G5) HP ProLiant DL380 Generation 5 (G5)
Rear View: Rear View: Rear View: Rear View:
1. Torx service tool
2. Optional pass through cable door
3. Two Embedded NC373i Multifunction Gigabit Server
Adapters with TCP/IP Offload Engine
4. Hot plug power supply bays, redundancy option (High
performance models include redundant power supply)
5. Integrated Lights-Out 2 (iLO 2) Remote management port
6. Video Port
Two USB 2.0 Ports
8. Serial Port
9. Keyboard Port
10. Mouse PS/2 Port
11. Two low-profile PCI Express x8 slots. Slot 1 is consumed by
the P400 Smart Array controller. (Base and Performance
models)
12. Three full-size PCI Express slots in standard cage (or
optional mixed PCI-X/E expansion cage)
Page 1
