Features

• STM32H7B3LIH6Q Arm
TFBGA225 package
• 7" 800x480 WVGA TFT LCD color module with RGB parallel interface and capacitive touch panel with I
interface
• 1/4" color CMOS QSXGA (5 Mpixels) camera module with DCMI and I
• USB OTG HS and USB OTG FS
• On-board current measurement
2
• I S/SAI audio codec
• 512-Mbit Octo‑SPI NOR flash, 8‑Mx32bit SDRAM, 1‑Mx16bit SRAM, and 8‑Mx16bit NOR flash
• Four color user LEDs
• Reset, wake up, and tamper push-buttons
• 4-direction joystick with a selection button
• Potentiometer
• Coin-battery cell holder for power backup
• Power-metering and temperature-monitoring demonstration with 2 dual-channel, sigma-delta modulators
®
• Wi‑Fi module compliant with 802.11 b/g/n
• Board connectors:
– Two USB Micro-AB
– Two microSD
– Octo‑SPI NOR flash module connector
– Stereo line out headset jack including analog microphone input
– Stereo line in headset jack
– Two DB9 for external RS-232 port and CAN FD
– JTAG and ETM trace debugger
– Connectors for ADC and DAC
– I/O expansion connectors
– DFSDM microphone daughterboard expansion connector
– Motor-control interface expansion connector
2
– I
• Flexible power-supply options: ST-LINK USB V
• On-board STLINK-V3E debugger/programmer with USB re-enumeration capability: mass storage, Virtual
COM port, and debug port
• Comprehensive free software libraries and examples available with the STM32Cube MCU Package
• Support of a wide choice of Integrated Development Environments (IDEs) including IAR Embedded
Workbench
