6.2

STM32H7B3I-EVAL mechanical drawing

MB1331 with 7'' LCD daughterboard (RGB)
Symbol
A1
A2
a
D
d
E1
E2
UM2662 - Rev 4
Figure 4. Mechanical dimensions (in millimeters)
Table 4. Mechanical dimensions (in millimeters)
Size Symbol
68.6 e
48.6 H
1.27 Lx1
3.5 Lx2
3.5 Ly1
108 Ly2
108 Mx
Hardware layout and configuration
Size Symbol
116.5 My
8 P1
33.5 P2
32.7 Q1
5.4 Q2
5.4 X
26.3 Y
UM2662
Size
32.7
21.4
60.7
50.6
10
173
169
