No screws or wall plugs are provided for the wall attachment due to variations in wall materials,
Before drilling into the wall you MUST check for any hidden services or pipework within the walls.
Attaching the tower unit to the wall
Fix the unit to the wall through the L-brackets as
shown in the image (fixings are not provided).
Securing to adjacent units
Clamp together the two units, checking the
front edges are level and flush.
Using the screws provided, 1x30mm screw
should be fixed into each corner of the
carcase side.
The screws can be concealed by placing
them behind the shelf or behind the hinge
plates. The cover caps can be used to hide
any visible screw heads that remain.
Placing the shelves into position
Position the shelf pegs into the pre-drilled
holes.
Place the shelves into position so the pins of
the shelf pegs are inserted into the pre-drilled
holes.
The shelves touch the back panel when
installed, if there is a gap between the back
panel and shelves then the shelves have been
installed back to front and need to be rotated.
Remove the masking tape from the bin
frontal.
thickness, and construction.
