Wren Kitchens INFINITY Fittings Manual page 6

Adding the door buffers
Position the door buffer at the top and
bottom corners of the carcase, as illustrated in
the image.
Adjusting the hinges and installing the
cover caps
To adjust the hinges, use a screwdriver as
required at points 1 and 2.
Point 1 – Will secure the frontal in place.
Point 2 – Will adjust the height of the frontal.
To move the frontal left or right, and in or out,
loosen the screw at point 1 and adjust the
frontal, tighten point 1 to secure the frontal in
place.
Fit the hinge cover caps to the hinges by
pressing down until the cap clicks.
Cleaning the unit
Finally, the unit should be thoroughly
cleaned to remove any debris that may have
accumulated during the installation.
1
2
Page 6
