Remember to take care when unpacking. Please keep your workspace clean, clear
and tidy when working. This will help keep all items safe from any damages. Any
un-needed cardboard or plastic should be flattened down and placed in the bin.
A minimum of two people will be needed to lift the unit.
Unpacking the parts and fittings
Remove all content from the packaging and
ensure to familiarise yourself with all unit
parts and fittings.
All parts and fittings should be kept on a
clean and level surface and the shelf placed in
the door safe along its longest length.
Removing the frontal (if required)
Before installing the unit, remove the frontal
by removing the cover cap and releasing the
screw shown in the diagram and unhooking
the door
Remove the frontal by un-clipping the lift
hinge mechanisms from each of the bracket.
Place the frontal in the door safe along its
longest length.
Installing the L-bracket
Secure the L-brackets internally in both
bottom corners of the unit at the rear using
2x15mm screws per bracket.
