Lifting the unit into place
Lift the unit against the wall slightly higher
than its finished height. Insert the bracket
into the wall hanging brackets to hook the
unit and lower the unit down, as illustrated.
Before releasing the unit, gently tug it
to ensure it is securely supported by the
hanging brackets.
Adjusting the wall brackets
Using the points below, adjust the unit to suit.
Point 1 – Turn this screw to adjust the height
of the unit.
1
Point 2 – Turn the screw to adjust the depth
2
of the unit.
No screws or wall plugs are provided for attaching the unit to the wall.
This is due to variations in wall construction.
Securing the unit to the wall
Secure the unit to the wall by screwing
through the L-bracket into the wall.
