EXPLODED VIEWS
Hot water taps
Spare parts list
POS.
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
*26
*27
*28
*29
*30
Note:
i
Parts 21, 22, 23, 24 and 25 are for a machine with automatic water tap.
PCS Part No.
1 C30370070
1 C30370060
1 C30370050
1 C30370040
1 C30370065
2 C30370020
1 C30370030
1 C30370010
1 C30370140
1 C40000015
1 C25012521
1 C30370110
1 C30370130
1 C30370120
1 C25097960
1 C50010080
1 C30370076
1 C30370077
1 C30370075
1 C70000010
- C15000325
- C30370080
- C30000050
- C35010056
- C15000330
1 C60000100
- C60000103
2 C30000510
1 C30000003
1 C35010035
Description
Tap Body
Close Nut
Closing Shaft M-6
Shaft Spring
Push Cap
Shaft Ring
Gasket
Tap Fitting
Tap Fixing Nut
High Group Tap Knob
Stainless Steel Knob Washer
Water/Steam Knob Pin
Steam Tap Knob Anagram
Water Tap Knob Anagram
Steam/Water Tap Nut M6-Din 979
Gasket Tap Steam/Water Te on
Spring Steam/Water Tap
Gasket Tap Steam/Water Brass
O-Ring 12.1X2.7mm
Nut 3/8 For Steamer
Tap Steam/Water Body
Lanza Agua Mod Classic
Nozzle Water Tap Complete
Hot Water Pipe For High Group
Tap Hot Water Complete
Parker Solenoid 220V Quarter
Parker Solenoid 110V Quarter
Fitting Cone 1/4 X 1/4 Electron
Male Female Reducer 3 / 8X1 / 4
Water Throwing Curve
