EXPLODED VIEWS
Water system_ZIRCON 2Gr 3 boilers
Spare parts list
POS.
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
PCS Part No.
2 C15000370
1 --------
1 C60000062
2 C35040117
1 C35110530
2 C35040118
2 C15000050
2 C35110113
1 --------
1 C60000008
2 C35020010
2 C35040476
2 C35110000
2 C60100045
1 C35110464
1 C35110012
1 CESC00093
1 C70001000
1 ESC00010
1 C35900180
1 C35900020
Description
Tap Steam Eleg./Mega ComP 4H BF
Water throws + E.V. 2-way 1/4G
D-40 One Reading Manometer Orman
4Ltrs Grinder's Steam Pipe
Pipe Manometer
Pipe Water Filling Mini
Group Espresso Preass
Pipe Steam Tap
Boiler Assembly ZIRCON 2GR 3 boilers
Pressostat Piris Ce
Of ce Water Tube
Entry Tube D12 Of ce Grinder
Pipe Group Right Return 2Gr
Flowmeter Ul/Netw. Brass Tef+Led
Pipe Distribution 2Gr Mc
Pipe Drainage Boiler 2Gr
Water Spliter
Drain Filter + High Group
CREM motobomba 220V
180cm Hose
30cm Hose
ZIRCON
