Expobar ZIRCON MINI 1GR CONTROL Service Manual page 77

EXPLODED VIEWS
Group head
Spare parts list
POS. PCS
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Note:
i
Sets C60000112 and C60000115 do not include no. 17 screws.
The CESC50000 set is designed for threaded group bodies (models prior to 2004).
Pos. 13/14 can be used for old and worn out seals/group heads to ensure proper sealing.
Part No.
1 C30200035
1 C50010040
1 C70000009
1 C30200061
1 C30200026
1 C25091250
1 C30200010
1 C30200040
1 C75000010
1 C75000081
- C75000083
- C75000085
- C75000090
- C75000095
- C30000043
1 C30000040
4 C25091210
2 C50000100
1 C50000010
1 C50020000
- C50020020
- C50020010
1 C30200026
1 C30200070
- CESC50000
1 C60000112
1 C60000115
- C15000050
Description
Long Plug 1/2 Group
21.7*25.7*2 G/C-G Te on Gasket
Group Te on Injector Rev3
Group Te on Injector Rev3
Te Water Reduc. Holder 4X6x65
Allen Screw 6*10 Din-912 Group
Crem Brewing Group Body
Diffuser
Shower
8mm Group Head Gasket
Filter 8.5Mm
Filter 9Mm
EXTRA SEAL FOR GASKET 0,5 Mm
EXTRA SEAL FOR GASKET 1 Mm
High Group Brewing Group Thread
Brewing Group Thread
Allen Screw 4X12 Din-912
O-Ring 6.07X1.78 Fkm Fda
Green Body Flat Group Joint
3.5*18.2*2 Te on Hot Water Reducto
Chicle Te on 2'5 (2'5X18'2X2)
Chicle Te on 2 (2X18'2X1)
Te on Tube 4X6x55
Acople Tubo Portachicle
Injector Kit Complete
Gro Head Electrov. Parker 220V
Gro Head Electrov. Parker 120V
Group Espresso Preass
ZIRCON
