Expobar ZIRCON MINI 1GR CONTROL Service Manual page 59

EXPLODED VIEWS
Water system_ZIRCON mini
Spare parts list
POS. PCS
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
Note:
i
The optional mini mill 0C000021 models only used on 1Gr models.
Part No.
1 C15000370
1 C60000062
1 C35040117
1 C35110530
2 C15000050
1 C35040006
1 C35110002
1 C35110003
3 CESC00100
1 --------
1 C35040106
1 C60000008
2 C35040118
1 C35040105
1 C15000330
1 CESC00098
1 C70001005
1 C70001001
1 CESCMPE00
1 C35900040
1 C35900180
Description
Tap Steam Eleg./Mega Comp 4H Bf
D-40 One Reading Manometer Orman
4Ltrs Grinder's Steam Pipe
Pipe Manometer
Group Espresso Preass
Pipe Group Left Return Mini
Pipe Group Right Inlet
Pipe Group Left Inlet
Magnets Set
Boiler Assembly G-10 Mini
Pipe Pressure Sensor Mini
Pressostat Piris Ce
Pipe Water Filling Mini
Pipe Group Right Return Mini
Tap Hot Water Complete
Piping Mini Control 2 Std&Ta
Drain Cup Cover
Drain Cup With Thread
Motor&Pump Ass Eco
55Cm Hose
180Cm Hose
ZIRCON
59
