Expobar ZIRCON MINI 1GR CONTROL Service Manual page 87

EXPLODED VIEWS
Steam tap
Spare parts list
POS. PCS
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
Part No.
1 C30370070
1 C30370060
1 C30370050
1 C30370040
1 C30370065
2 C30370020
1 C30370030
1 C30370010
1 C30370140
1 C40000015
1 C25012521
1 C30370110
1 C30370130
1 C30370120
1 C25097960
1 C50010080
1 C30370076
1 C30370077
1 C30370075
1 C70000010
1 C70000035
1 C50010090
1 C30370195
1 C15000325
- C30370095
- C35010052
- C15000370
Description
Tap Body
Close Nut
Closing Shaft M-6
Shaft Spring
Push Cap
Shaft Ring
Gasket
Tap Fitting
Tap Fixing Nut
High Group Tap Knob
Stainless Steel Knob Washer
Water/Steam Knob Pin
Steam Tap Knob Anagram
Water Tap Knob Anagram
Steam/Water Tap Nut M6-Din 979
Gasket Tap Steam/Water Te on
Spring Steam/Water Tap
Gasket Tap Steam/Water Brass
O-Ring 12.1X2.7mm
Nut 3/8 For Steamer
Protection Rubber
O-Ring 6*1
Nozzle Steam Tap 3H M8.5 With Gaske
Tap Steam/Water Body
Pipe Steam Eleg./Megacrem Wo Nozzle
Pipe Steam Eleg./Mega Ta Wo Nozzle
Tap Steam Eleg./Mega Comp 4H Bf
