Assembly Instructions
1
Determine the orientation you would like for your desk. As you are building this upside down
remember that the return worksurface needs to go on the opposite side to which you want it.
Left Hand Side
2
Insert the Middle Wing Bracket into the main frame on the side in which your return
worksurface is going to be placed (2a). Place the corresponding Left or Right Wing Bracket
into the other side (2b) and place the other wing bracket into the return frame (2c). Secure
using (6) M6 x 14 Machine Screws (2d). Tighten with the 4mm Allen Key (2e).
2d
30
2d
2b
Right Hand Side
2d
2e
2a
2e
2c
