eFloat Go (Two-Column Kit, Beamless)
Disassembly Instructions
Tools Required
Safety Glasses
Phillips Head Screwdriver
Polypropylene
1
Initial Disassembly
3
Step 1
Place the table upside-down on a protective surface.
Step 2
Steel
Remove ST5x20mm screws (if any),
securing cable ties.
2
Step 3
Remove cable ties (if any).
Step 4
Cable ties are no longer attached to worksurface.
4
Some components may not be recyclable in your area.
REV-00
