Humanscale efloat next Assembly Instructions Manual page 26

8
Plug the Hand Switch into the Control Box (8a). Connect the two legs to the Control Box
(8b), using the Connecting Cable (8c) for the leg furthest away from the Control Box. Plug
the Power Cord into the Control Box (8d).
Note: As an option, use the provided (10) Cable Ties to secure cables to underside of
worksurface (8e), with either double sided tape or the (10) ST4 X 10 Flat Head Wood Screws.
8a
8b
9
Flip your table right side up and plug into outlet. Reset the desk per instructions in following
section.
YOU MUST RESET THE DESK BEFORE USE. FOLLOW INSTRUCTIONS ON INITIAL SETUP/
26
8d
8b
RESET UNDER HAND SWITCH (SEE PG. 43 or 44)
8c
8e
