Introduction to the Decoder Module,
Terminal Blocks
TB1 and TB2 = Connection to coded stations or relay contacts.
TB3 = Power and RUI Connections
TB3-1
= RUI+
TB3-2
= RUI-
TB3-3
= RUI+
TB3-4
= RUI-
TB3-5
= +24 V
TB 3-6
= +24 V
TB3-7
= 0 V
TB3-8
= 0 V
Continued
