Simplex 4100-0136 Installation Instructions Manual page 29

LCD Messages,
4100 Operator
Interface Panel
Operation
Continued
The front panel operations relating to coded devices reported by the decoder module will be the
same as with MBZAM devices with few exceptions. Sample 4100 LCD displays for the Alarm,
Trouble, and Disable states of a coded station are shown below.
CUSTOM LABEL
FIRE MONITOR ZONE
CUSTOM LABEL
FIRE MONITOR ZONE
CUSTOM LABEL
FIRE MONITOR ZONE
The disable function is used to prevent a point from causing an alarm at the Operator Interface
Panel. A point that alarms while disabled will not be indicated as an alarm at the Operator
Interface Panel, but will be indicated on the decoder LCD. When the point is enabled from the
Operator Interface Panel, a 60-second timer will count down to zero. After the timer expires,
alarms from the coded stations are enabled.
Since the decoder is not actually communicating with the coded stations, some troubles associated
with MAPNET II communication errors are different, or not applicable. A "WRONG DEVICE"
trouble will be indicated if a coded station is not programmed as an MBZAM device. The "BAD
ANSWER" trouble is not applicable, and is not used. If a device is programmed in the 4100, but
no code is indicated at the decoder, a "NO ANSWER" trouble will be indicated for that device. If
devices are programmed at the decoder, but not at the 4100, an "EXTRA DEVICE" trouble will be
indicated for that decoder channel.
(40 CHARACTER MAXIMUM)
(40 CHARACTER MAXIMUM)
OPEN CIRCUIT TROUBLE
(40 CHARACTER MAXIMUM)
DISABLE TROUBLE
29
ALARM
