Simplex 4100-0136 Installation Instructions Manual page 24

Device Programming,
Programming the
Decoder
Continued
1. Place switch SW1 in the <PROG> position (see Figure 1 for the location of SW1 if
necessary). The decoder LCD displays the code for the first device on the decoder's first
MAPNET II channel.
2. Press the <MODE> key. The display shows the following message.
PRESS "ENTER" TO
CLEAR ALL CODES
3. Press the <ENTER> key if you want to erase all of the codes previously entered. When you
press the <ENTER> key, the decoder responds with the following verification message.
VERIFY CLEAR
ALL CODES Y/N
Press the <ENTER> key if you want all of the codes cleared from the EPROM. As soon as
the <ENTER> key is pressed, the decoder LCD displays the screen for the first device on the
decoder's first MAPNET II channel, as shown below. Skip ahead to step 4 if and after you
press the <ENTER> key.
However, if you do not want to clear all the coded information, but rather want only to make
changes to some of the device codes, press the <MODE> key again. The LCD shows the
following message.
Press the <ENTER> key. The decoder shows the screen for the first device on the decoder's
first MAPNET II channel with the previously programmed device code, as shown below.
4. Select the desired channel by placing the cursor under the channel letter and pressing the
<INC> (Increment) key or <DEC> (Decrement) key.
Note: The decoder refers to its channels as "A" and "B", since the MAPNET II channel
numbering information used by the 4100 panel is not available to the decoder.
CHNL A DEV 001
CODE 12-07-01
CHNL A DEV 001
CODE
PRESS "ENTER" TO
PROGRAM CODES
CHNL x DEV xxx
CODE
24
Continued on next page
