Simplex 4100-9600 Installation Instructions Manual

Simplex 4100-9600 Installation Instructions Manual

Communication and audio interface modules
Hide thumbs Also See for 4100-9600:

Advertisement

Table of Contents

This publication describes the installation procedure for Transponder Interface Cards (TICs),
Introduction
Audio Riser Modules, and the Network Audio Riser Controller Module for installation in 4100U
and 4100ES Fire Alarm Control Panels.
This product is compatible with 4100U and 4100ES Fire Alarm Control Panels (FACP).
This publication also includes connections that provide the Non-Alarm Audio (NAA) Interface
feature.
IMPORTANT: Verify FACP System Programmer, Executive, and Slave Software
In this Publication
© 2005-2011 SimplexGrinnell LP. All rights reserved.
Specifications and other information shown were current as of publication and are subject to change without notice.
Simplex and the Simplex logo are trademarks of Tyco International Ltd. and its affiliates and are used under license.
compatibility when installing, or replacing system components. Refer to
the Technical Support Information and Downloads website for compatibility
information.
firealarmresources.com
Communication and
Audio Interface Modules
Installation Instructions
Topic
See Page #
2
3
8
9
10
12
13
21
23
26
27
574-844
Rev. P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4100-9600 and is the answer not in the manual?

Questions and answers

Related Manuals for Simplex 4100-9600

Summary of Contents for Simplex 4100-9600

  • Page 1: Table Of Contents

    574-844 Specifications and other information shown were current as of publication and are subject to change without notice. Simplex and the Simplex logo are trademarks of Tyco International Ltd. and its affiliates and are used under license. Rev. P firealarmresources.com...

  • Page 2: Cautions And Warnings

    DO NOT INSTALL ANY SIMPLEX® PRODUCT THAT APPEARS DAMAGED - Upon unpacking your Simplex product, inspect the contents of the carton for shipping damage. If damage is apparent, immediately file a claim with the carrier and notify an authorized Simplex product supplier.

  • Page 3: Tics And Audio Riser Modules

    Audio riser modules support Class A and Class B analog wiring, as well as Style 4 and Style 7 digital audio wiring. Table 1. TIC, Audio Riser, and Riser Controller PIDS PID List Description Part Number 4100-9600 Basic Transponder 742-866 (Expansion Bay with PDI and Basic TIC) 4100-9601 Local Mode Transponder...
  • Page 4 TICs and Audio Riser Modules, Continued The Local Mode TIC A local mode TIC acts as a controller for the transponder cabinet if the TIC loses communication with the Master Controller. When operating in local mode, an alarm on any fire alarm input circuit will cause all alarm notification appliance circuits to activate.
  • Page 5 TICs and Audio Riser Modules, Continued TIC LEDs TIC module LEDs provide the following status information: LED1. Illuminates to indicate communication loss with the host panel. LED2. Illuminates when an RUI ground fault search is active. LED3. Illuminates when Local Mode is active (4100-0625 Local Mode TIC only). LED4.
  • Page 6 TICs and Audio Riser Modules, Continued • Local mode operation is limited to general alarm. Any point type listed in Table 4 is valid for Local Mode local mode alarm operation. Note that the point must be an alarm-type point. On any alarm input, all circuits listed in Table 5 will activate.
  • Page 7 TICs and Audio Riser Modules, Continued Local Mode Table 4. Alarm Input Devices Point Type Description Curr. Lim. Short FIRE Fire alarm (generic) Alarm Alarm WATER Waterflow switch Alarm Alarm HEAT* Heat detector Alarm Alarm DUCT* Duct detector Alarm Alarm FLAME Flame detector Alarm...

  • Page 8: System Guidelines

    System Guidelines • RUI Guidelines All wiring is 18 AWG (0.8231 mm ) (minimum) and 12 AWG (3.309 mm ) (maximum). • All wiring is supervised and power-limited. • All wiring that leaves the building requires overvoltage protection. Install the module inside an UL-Listed electrical box wherever wire enters or exits the building.

  • Page 9: Network Audio Riser Controller Module

    Network Audio Riser Controller Module Audio Network An audio network contains one node with an audio controller module Configuration (4100-1210 Analog Controller Board or 4100-1211 [or -1311] Digital Controller Board), and local analog or digital amplifiers. Some configurations may have an audio controller module located in a transponder end node;...

  • Page 10: Configuration

    Configuration Overview The TIC and all other modules to be mounted in the transponder cabinet and attached expansion bays must be configured to operate correctly in the system via their DIP switch and jumper ports. This section describes the hardware configuration for TICs and the Network Audio Riser Controller Module.
  • Page 11 Configuration, Continued Setting the Address, Table 7. TIC & Network Audio Riser Controller Module Addresses Address SW 1-2 SW 1-3 SW 1-4 SW 1-5 SW 1-6 SW 1-7 SW 1-8 Address SW 1-2 SW 1-3 SW 1-4 SW 1-5 SW 1-6 SW 1-7 SW 1-8 firealarmresources.com...

  • Page 12: Mounting

    Mounting Mounting TICs, Audio Riser Modules, and Network Audio Riser Controller Modules are 4” X 5” modules Instructions and are mounted per the following information. IMPORTANT: The TIC or Network Audio Riser Controller Module should be mounted in the upper left position of the bay. The audio riser module must be mounted directly below the TIC or Network Audio Riser Controller Module.

  • Page 13: Wiring

    Wiring TIC/Motherboard Use Figure 5 to connect the TIC to a motherboard in another bay. Interconnections TMPR SW 24C INPUT SHLD LED4 LED5 POWER/ COMM HARNESS 734-078 4100 LED1 COMM LOSS LED2 G.F. SEARCH PDI 1 AUDIO RISER CARD 4100 POWER DISTRIBUTION INTERFACE ASSY 566-084 HARNESS 734-008...
  • Page 14 Wiring, Continued Overview The TIC (except for the Network Audio Riser Controller Module) must be connected to the host panel via RUI cabling. This section explains how to wire the two together, and how to set up a system with multiple transponders connected to the same host panel. RUI Wiring RUI cabling can be accomplished either through Class A or Class B wiring.
  • Page 15 Wiring, Continued Overview This section describes the Class A and Class B connections from audio controllers to audio risers, which in turn connect to a TIC or Network Audio Riser Controller Module. Wiring configurations are shown for both analog and digital controllers and risers. Analog Figure 8 is an illustration of Class A and Class B analog wiring from the analog audio controller to Interconnections...
  • Page 16 Wiring, Continued The 4100U or 4100ES may be connected to the 4100 Legacy Audio Controller via the 4100U Connecting the Audio Riser and the Network input on the Legacy Controller. The 4100U and 4100ES use a 4100U/4100ES Analog 10VRMS Analog Audio riser. In order to interface to a legacy 4100 Audio Controller Network Riser to Legacy 4100 input, an isolation/step-down transformer must be used.
  • Page 17 Wiring, Continued   Amplifier and The low level (1Vp‐p) audio output from the legacy controller to the local amplifiers must be Harness converted from an unbalanced signal to a balanced signal in order to pass the distortion Connections requirements for this configuration. This is accomplished by a new Isolation Transformer harness, PN 0734‐231.
  • Page 18 Wiring, Wiring, Continued Continued Digital (For Constant Supervision applications with 4100U Master Firmware Revision 11.08 or Interconnections later) Figure 11 is an illustration of Class A and Class B digital wiring from the digital audio (4100-1311 Digital controller to risers connected to TICs or the Network Audio Riser Controller Module. Audio Controller FigureTag FD4-844-02 [Constant...
  • Page 19 Wiring, Continued Distributed A Distributed Microphone is used between audio nodes in a network system where each node has Microphone its own local audio (its own Digital Audio Controller) but needs to be able to play the microphone Interconnections channel from a separate node’s Digital Audio Controller. For a distributed microphone application, the 4100-0622 Digital Riser Interface (566-407) has a single digital to analog converter that can be set to convert any single channel of the Digital Audio Riser (DAR) stream to analog.
  • Page 20 Wiring, Continued Multiple Digital A distributed line level signal is used between audio nodes in a Multiple Digital Command Centre Command Center (MCC) network system where nodes have local analog audio but need to be able to play the Interconnections microphone, the tones, and the messages from a separate node’s Digital Audio Controller.

  • Page 21: Digital Audio Riser Module (566-407,-833)

    Digital Audio Riser Module (566-407, -833) Overview This section describes configuration settings for the 4100-0622 Digital Audio Riser (DAR) Module (566-407) and the 4100-1341 MCC Digital Audio Riser Module (566-833). Locations on the Figure 14 shows the important component locations on the 4100-0622 Digital Audio Riser (DAR) Digital Audio Riser Module.
  • Page 22 Digital Audio Riser Module, Continued Switches and DIP Switches Indicators Two 4-position switches (SW1 & SW2) allow for configuration of the D to A channel, DAR density, and module outputs for the 4100-0622, -1341 Digital Audio Riser Module. See Table 9. Table 9.

  • Page 23: Non-Alarm Audio (Naa) Interface

    Digital Audio Riser Module, Continued • Jumpers: Switches and Indicators Two jumpers allow for configuration of the 4100-0622, -1341 Digital Audio Riser Module (566-407, -833 respectively) as shown in Table 10. Table 10. Jumper Positions for the 4100-0622, -1341 Digital Audio Riser Module P4: Analog Audio input level (for Non-Alarm Audio [NAA] Application) Position Audio Input Level...
  • Page 24 Non-Alarm Audio (NAA) Interface Overview This section describes the Non-Alarm Audio (NAA) Interface using a circuit on the 4100-0622 Digital Audio Riser (DAR) Module (566-407) or the 4100-1341 MCC Digital Audio Riser module (566-833). This function provides a way to interface a non-alarm audio source to Channel 2 of the Power Distribution Interface (PDI).
  • Page 25 Non-Alarm Audio (NAA) Interface, Continued NAA Wiring Refer to Figure16 to wire for the NAA Interface application 4100-0623 NETWORK AUDIO RISER CONTROLLER MODULE 4100-0622 DIGITAL AUDIO RISER INTERFACE OR THE 4100-1341 MCC DIGITAL AUDIO RISER INTERFACE CHANNEL NAA IN TO CUSTOMER- SUPPLIED EQUIPMENT Figure 16.

  • Page 26: Field Replacement Of The Digital Audio Riser Module (566-243)

    Field Replacement of the Digital Audio Riser Module (566-243) Overview This section applies only to the field replacement of the Digital Audio Riser (DAR) Module (566- 243) with the later version of this module (566-407). Configuration and The following configuration and wiring information applies when replacing the 566-243 module Wiring of the Digital with the 566-407 module.

  • Page 27: Digital Audio Pdi Termination Plug

    Digital Audio PDI Termination Plug Overview A Digital Audio Riser Termination Plug (734-183) is provided with every Digital Audio Controller or Digital Audio Riser Module. You must use this termination plug to properly terminate the Digital Audio Signal on the PDI. Installing a Digital To properly terminate the Digital Audio Signal on the PDI, you must install the termination plug Audio PDI...
  • Page 28 574-844 Rev. P firealarmresources.com...
